Wastewater/Activity/PacpInspection/1.0Jul 26, 2016, 06:22 AM
02 0720_02 0719A_20160726_004539.mp4
- Date
- 07/25/2016
- W/O
- 574316
- Weather
- Dry
- Operator/Surveyor
- J. HARTOOG
- Sewer ID
- Z00294
- PipeID
- P03274
- Time
- 11:22 PM
- Certificate
- U-507-3386
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K3662
- Sewer Name
- 02 OLD RIVER SCHOOL ROAD TRUNK, SECTS 1&2
- City
- DOWNEY
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 29
- Purpose
- Routine Assessment
- Project
- WO_574316_TV02111_JUNE2016
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 18 in.
- Width
- 18 in.
- Upstream MH
- 02 0720
- Downstream MH
- 02 0719A
- Dir. of Survey
- Downstream
- Length Surveyed
- 321.1 ft.
- Total Length
- 321.1 ft.
- Structural Index
- 3
- Structural Quick
- 3400
- Structural Rating
- 12
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 12
Observation photos (3)
0 ft. - Water Level, 35 %of cross sectional area
6.5 ft. - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 4"
275.4 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES
Observations (16)
| Distance | Code | Observation |
|---|---|---|
| 314.2 | FL | — |
| 89.6 | FL | — |
| 95.4 | TFA | — |
| 0 | MWM | — |
| 275.4 | CM | — |
| 5.1 | FL | wandering 30% |
| 71.2 | FL | — |
| 220.2 | TFA | — |
| 0 | MWL | — |
| 98 | TFC | — |
| 6.5 | TFC | — |
| 321.1 | AMH | 02 0719A |
| 9.4 | TFC | — |
| 222.8 | TF | — |
| 0 | AMH | 02 0720 |
| 98 | FL | wandering 30% |
Properties (4)
- additional_info
- SC305541
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2016-07-25T23:22:47-07:00
