Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 16, 2018, 03:31 PM

  • 01 1068_01 1067_5162018_090111.mp4

Date
05/16/2018
W/O
PENDING
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z00211
PipeID
P01916
Time
8:31 AM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7710
Sewer Name
01 HUNTINGTON PARK RELIEF EXTENSION TRUNK
City
SOUTH GATE
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
07
Purpose
Maintenance Related
Project
20180516DF_HUNTINGTON_PARK_RELIEF_EXTENSION_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
18 in.
Upstream MH
01 1068
Downstream MH
01 1067
Dir. of Survey
Downstream
Length Surveyed
493.6 ft.
Total Length
493.6 ft.
Structural Index
2
Structural Quick
2100
Structural Rating
2
O&M Index
2
O&M Quick
2400
O&M Rating
8
Overall Index
2
Overall Quick
—
Overall Rating
10
Pipe schematic from manhole 01 1068 to 01 1067
MH: 01 1068MH: 01 1067downstream0 ft. AMH - Upstream Manhole, Survey Begins - 8:35 AM0.1 ft. TFA - Tap Factory Made Active, at 09 o'clock, -, within 8 inches of joint: YES, 4"0.1 ft. MWL - Water Level, 15 %of cross sectional area0.1 ft. MWM - Water Mark, 20 %of cross sectional area2 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start74.8 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: YES, 4"134.1 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: YES, 4"196.7 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: YES, 4"240.1 ft. MGP - General Photograph240.1 ft. TFD - Tap Factory Made Defective, at 12 o'clock, -, within 8 inches of joint: YES, 4" - 85% ROOTS287 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: YES, 4"325.9 ft. TFD - Tap Factory Made Defective, at 12 o'clock, -, within 8 inches of joint: YES, 4" - 95% ROOTS325.9 ft. MGP - General Photograph365.3 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: YES, 4"408.5 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: YES, 4"447.3 ft. MGP - General Photograph447.3 ft. TFD - Tap Factory Made Defective, at 12 o'clock, -, within 8 inches of joint: YES, 4" - 100% ROOTS447.3 ft. MGP - General Photograph486.1 ft. MGP - General Photograph486.1 ft. TFD - Tap Factory Made Defective, at 12 o'clock, -, within 8 inches of joint: YES, 4" - 45% ROOTS491.8 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish493.6 ft. AMH - Downstream Manhole, Survey Ends - 9:31 AM

Observation photos (8)

  • Upstream Manhole, Survey Begins - 8:35 AM

    0 ft. - Upstream Manhole, Survey Begins - 8:35 AM

  • General Photograph

    240.1 ft. - General Photograph

  • Tap Factory Made Defective, at 12 o'clock, -, within 8 inches of joint: YES, 4" - 85% ROOTS

    240.1 ft. - Tap Factory Made Defective, at 12 o'clock, -, within 8 inches of joint: YES, 4" - 85% ROOTS

  • General Photograph

    325.9 ft. - General Photograph

  • General Photograph

    447.3 ft. - General Photograph

  • General Photograph

    447.3 ft. - General Photograph

  • General Photograph

    486.1 ft. - General Photograph

  • Tap Factory Made Defective, at 12 o'clock, -, within 8 inches of joint: YES, 4" - 45% ROOTS

    486.1 ft. - Tap Factory Made Defective, at 12 o'clock, -, within 8 inches of joint: YES, 4" - 45% ROOTS

All inspections of P01916Work order PENDING

Observations (22)

DistanceCodeObservation
2SSS—
325.9TFD95% ROOTS
240.1MGP—
447.3MGP—
365.3TF—
491.8SSS—
408.5TF—
486.1MGP—
486.1TFD45% ROOTS
325.9MGP—
196.7TF—
447.3TFD100% ROOTS
447.3MGP—
287TF—
134.1TF—
0.1TFA—
0.1MWL—
493.6AMH9:31 AM
74.8TF—
0AMH8:35 AM
240.1TFD85% ROOTS
0.1MWM—

Properties (4)

additional_info
ON SCREEN PIPE SIZE IS WRONG. PIPE IS AN 18"
custom_field_two
3
customer
LACSD
datetime
2018-05-16T08:31:51-07:00
