Wastewater/Activity/PacpInspection/1.0Mar 8, 2018, 10:16 AM
18 0417_18 0416_08032018_033143.mp4
- Date
- 03/08/2018
- W/O
- 690550
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00699
- PipeID
- P14252
- Time
- 2:16 AM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5478
- Sewer Name
- 18 SANTA FE STREET RELIEF TRUNK
- City
- WHITTIER
- Loc. details
- Easement/Right of Way
- Location Code
- D
- Use of Sewer
- Sanitary Sewer
- District
- District 18
- Page No.
- 21
- Purpose
- Routine Assessment
- Project
- WO_690550_TV18173_MAR2018
- Sewer Type
- Gravity
- Material
- NRCP
- Shape
- Square
- Height
- 18 in.
- Width
- 18 in.
- Upstream MH
- 18 0417
- Downstream MH
- 18 0416
- Dir. of Survey
- Downstream
- Length Surveyed
- 326.3 ft.
- Total Length
- 326.3 ft.
- Structural Index
- 3
- Structural Quick
- 3100
- Structural Rating
- 3
- O&M Index
- 3
- O&M Quick
- 4121
- O&M Rating
- 6
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 9
Observation photos (2)
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start
2 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (15)
| Distance | Code | Observation |
|---|---|---|
| 324.6 | DAGS | — |
| 0 | MWL | — |
| 326.3 | MGO | CAPPED CONNECTION AT MH 9 O'CLOCK |
| 324.6 | SAP | — |
| 326.3 | AMH | 18 0416 |
| 326 | MGO | Surface Spalling throughout the reach from 7 to 5 oclock. |
| 326 | MGO | Magnesium Hydroxide Coat, 9 to 3 oclock, 20% |
| 0 | AMH | 18 0417 |
| 55.8 | TBA | — |
| 118.8 | TBA | — |
| 280.6 | TBA | — |
| 0 | MWM | — |
| 2 | DAGS | — |
| 2 | SAP | — |
| 184.5 | TBA | — |
Properties (4)
- additional_info
- SC358484
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2018-03-08T02:16:50-08:00
