Wastewater/Activity/PacpInspection/1.0Jul 24, 2017, 10:32 AM
C 0119B_A 0247_24072017_033352.mp4
- Date
- 07/24/2017
- W/O
- 635398
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00127
- PipeID
- P09642
- Time
- 3:32 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4757
- Sewer Name
- C JOINT OUTFALL C - UNIT 4B
- City
- LONG BEACH
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 03
- Page No.
- 20
- Purpose
- Routine Assessment
- Project
- WO_635398_TV03074_JUN2017
- Sewer Type
- Gravity
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 48 in.
- Width
- 48 in.
- Upstream MH
- C 0119B
- Downstream MH
- A 0247
- Dir. of Survey
- Downstream
- Length Surveyed
- 16.5 ft.
- Total Length
- 16.5 ft.
- Structural Index
- 4
- Structural Quick
- 5132
- Structural Rating
- 11
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 4
- Overall Quick
- —
- Overall Rating
- 11
Observation photos (2)
4.4 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
10.4 ft. - Surface Reinforcement Visible, from 01 to 04 o'clock, within 8 inches of joint: YES
Observations (11)
| Distance | Code | Observation |
|---|---|---|
| 0 | AMH | C 0119B |
| 4.4 | SAP | — |
| 16.5 | MGO | CONNECTION AT MH 9 O'CLOCK |
| 0 | MWL | — |
| 10.4 | SRV | — |
| 16.5 | AMH | A 0247 |
| 2.3 | MGO | MAG COAT |
| 16.5 | SAP | — |
| 16.5 | MGO | CONNECTION AT MH 12 O'CLOCK |
| 0 | MWM | — |
| 0 | MGO | CONNECTION AT MH 3 O'CLOCK |
Properties (4)
- additional_info
- SC345517
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2017-07-24T03:32:07-07:00
