Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 1, 2018, 08:25 PM

  • A 0431_A 0215_512018_133311.mp4

Date
05/01/2018
W/O
0686843
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z00323
PipeID
P08153
Time
1:25 PM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7698
Sewer Name
A JOA-1A LOS COYOTES WRP INTERCEPTOR
City
DOWNEY
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
29
Purpose
Routine Assessment
Project
20180427DF_JOA_1A_LOS_COYOTES_WRP_INTERCEPTOR
Material
Reinforced Concrete Pipe
Shape
Circular
Height
72 in.
Upstream MH
A 0431
Downstream MH
A 0215
Dir. of Survey
Downstream
Length Surveyed
2.5 ft.
Total Length
2.5 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
5
O&M Quick
5100
O&M Rating
5
Overall Index
5
Overall Quick
—
Overall Rating
5
Pipe schematic from manhole A 0431 to A 0215
MH: A 0431MH: A 0215downstream0 ft. MWM - Water Mark, 100 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 1:27 PM0 ft. MWL - Water Level, 100 %of cross sectional area2.1 ft. MGP - General Photograph2.1 ft. MGP - General Photograph2.1 ft. MGP - General Photograph2.1 ft. MGP - General Photograph2.5 ft. MSA - Survey Abandoned - HIGH WATER

Observation photos (5)

  • Upstream Manhole, Survey Begins - 1:27 PM

    0 ft. - Upstream Manhole, Survey Begins - 1:27 PM

  • General Photograph

    2.1 ft. - General Photograph

  • General Photograph

    2.1 ft. - General Photograph

  • General Photograph

    2.1 ft. - General Photograph

  • General Photograph

    2.1 ft. - General Photograph

All inspections of P08153Work order 0686843

Observations (8)

DistanceCodeObservation
2.1MGP—
0MWM—
2.1MGP—
2.1MGP—
2.5MSAHIGH WATER
2.1MGP—
0AMH1:27 PM
0MWL—

Properties (3)

custom_field_two
5
customer
LACSD
datetime
2018-05-01T13:25:06-07:00
