Wastewater/Activity/PacpInspection/1.0Nov 4, 2017, 12:26 PM
- Date
- 11/04/2017
- W/O
- #
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z01180
- PipeID
- P01465
- Time
- 5:26 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- G6859
- Sewer Name
- G JOINT OUTFALL G - UNIT 8
- City
- COMPTON
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 01
- Page No.
- 19
- Purpose
- Routine assessment
- Project
- JOINT_OUTFALL_G_UNIT_8
- Material
- RCP-CTL
- Shape
- Circular
- Height
- 36 in.
- Upstream MH
- G 0142
- Downstream MH
- G 0141
- Dir. of Survey
- Downstream
- Length Surveyed
- 350.5 ft.
- Total Length
- 350.5 ft.
- Structural Index
- 3
- Structural Quick
- 3M00
- Structural Rating
- 213
- O&M Index
- 5
- O&M Quick
- 5100
- O&M Rating
- 5
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 218
Observation photos (5)
2 ft. - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - SEVERE AGG AREAS OF MISSING TILES
8 ft. - General Observation - MISSING TILES 20% START
124.2 ft. - General Observation - 10% MISSING TILES START
212.9 ft. - General Observation - MISSING TILES 20% START
343.8 ft. - Surface Aggregate Projecting, from 10 to 02 o'clock, within 8 inches of joint: NO - SEVERE AGG
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 8 | MGO | MISSING TILES 20% START |
| 0 | MWL | — |
| 343.8 | SAP | SEVERE AGG |
| 212.9 | MGO | MISSING TILES 20% START |
| 350 | MGO | 20% MISSING TILES FINISH |
| 124.2 | MGO | 10% MISSING TILES START |
| 350 | SAP | SEVERE AGG AREAS OF MISSING TILES |
| 2 | MGO | MISSING TILES 100% 9:00 TO 3:00 |
| 350.5 | AMH | 6:20AM |
| 0 | MWM | — |
| 0 | AMH | 5:50AM |
| 2 | SAP | SEVERE AGG AREAS OF MISSING TILES |
Properties (4)
- custom_field_three
- MISSING TILES -SEVERE AGG VISIBLE
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2017-11-04T05:26:45-07:00
