Wastewater/Activity/PacpInspection/1.0Apr 22, 2016, 07:12 AM
0_C 0378_22042016_001258.mp4
- Date
- 04/22/2016
- W/O
- 563419
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00141
- PipeID
- P09842
- Time
- 12:12 AM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K3323
- Sewer Name
- C JOINT OUTFALL C - UNIT 8C
- City
- LAKEWOOD
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 19
- Page No.
- 06
- Purpose
- Routine Assessment
- Project
- WO_563419_TV19012_APRIL2016
- Sewer Type
- GRAVITY
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 27 in.
- Upstream MH
- 0
- Downstream MH
- C 0378
- Dir. of Survey
- Downstream
- Length Surveyed
- 37.6 ft.
- Total Length
- 37.6 ft.
- Structural Index
- 3
- Structural Quick
- 3727
- Structural Rating
- 35
- O&M Index
- 2
- O&M Quick
- 2700
- O&M Rating
- 14
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 49
Observation photos (4)
0 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
0 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
0 ft. - Upstream Manhole, Survey Begins - 0, CONNECTION NODE
0 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 0 | DAGS | — |
| 0 | MWM | — |
| 0 | MWL | — |
| 35.8 | SAP | — |
| 0 | SAP | — |
| 35.8 | SSS | — |
| 0 | AMH | 0, CONNECTION NODE |
| 0 | SSS | — |
| 35.8 | DAGS | — |
| 37.6 | AMH | C 0378 |
Properties (5)
- additional_info
- SC305601
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2016-04-22T00:12:30-07:00
- year_laid
- 19730406
