Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Apr 24, 2018, 07:34 AM

  • 01 0955_01 0954_4242018_005220.mp4

Date
04/24/2018
W/O
0701210
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00228
PipeID
P01792
Time
12:34 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H0838
Sewer Name
01 WRIGHT ROAD TRUNK
City
BELL
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
08
Purpose
Capital Improvement Program Assesment
Project
20180424MDM_WRIGHT_ROAD_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
24 in.
Upstream MH
01 0954
Downstream MH
01 0955
Dir. of Survey
Upstream
Length Surveyed
275.6 ft.
Total Length
275.6 ft.
Structural Index
3
Structural Quick
3222
Structural Rating
10
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
10
Pipe schematic from manhole 01 0954 to 01 0955
MH: 01 0954MH: 01 0955upstream0 ft. AMH - Upstream Manhole, Survey Ends - 1:30AM0.4 ft. MGO - General Observation - Conn. @ Mh, 9 O' Clock. Active41.3 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Finish - H69 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - HAIRLINE163.4 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Finish - SLIGHT213.9 ft. MGO - General Observation - 24" VCP221 ft. FC - Fracture Circumferential, from 12 to 01 o'clock, within 8 inches of joint: YES - SLIGHT235.7 ft. FC - Fracture Circumferential, from 12 to 01 o'clock, within 8 inches of joint: YES - HAIRLINE257 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - SLIGHT275.6 ft. AMH - Downstream Manhole, Survey Begins - 12:45AM275.6 ft. MWM - Water Mark, 20 %of cross sectional area275.6 ft. MWL - Water Level, 10 %of cross sectional area

Observation photos (3)

  • Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - SLIGHT

    18.6 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - SLIGHT

  • General Observation - 24" VCP

    61.7 ft. - General Observation - 24" VCP

  • Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - HAIRLINE

    206.6 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - HAIRLINE

All inspections of P01792Work order 0701210

Observations (12)

DistanceCodeObservation
206.6FLHAIRLINE
0AMH12:45AM
18.6FLSLIGHT
54.6FCSLIGHT
275.2MGOConn. @ Mh, 9 O' Clock. Active
112.2FLSLIGHT
234.3FLH
0MWM—
61.7MGO24" VCP
0MWL—
39.9FCHAIRLINE
275.6AMH1:30AM

Properties (6)

additional_info
REVERSE INSPECTION
custom_field_three
LONG SLIGHT FRACTURE JOINT TO JOINT LONGER
custom_field_two
2
customer
LACSD
datetime
2018-04-24T00:34:10-07:00
year_laid
19280228
