Wastewater/Activity/PacpInspection/1.0Dec 14, 2016, 08:44 AM
H 1527_H 1526 _14122016_004445.mp4
- Date
- 12/14/2016
- W/O
- 607756
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z01205
- PipeID
- P26027
- Time
- 12:44 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K3850
- Sewer Name
- H JOINT OUTFALL H - UNIT 8N RELIEF
- City
- COVINA
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 22
- Page No.
- 25
- Purpose
- Routine Assessment
- Project
- WO_607756_TV22093_DEC2016
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 24 in.
- Width
- 24 in.
- Upstream MH
- H 1527
- Downstream MH
- H 1526
- Dir. of Survey
- Downstream
- Length Surveyed
- 403.9 ft.
- Total Length
- 403.9 ft.
- Structural Index
- 4
- Structural Quick
- 5141
- Structural Rating
- 12
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 4
- Overall Quick
- —
- Overall Rating
- 12
Observation photos (3)
29.5 ft. - Broken Soil Visible, from 02 to 04 o'clock, within 8 inches of joint: YES
29.5 ft. - Fracture Multiple, from 02 to 09 o'clock, within 8 inches of joint: YES
42.4 ft. - Crack Multiple, from 10 to 12 o'clock, within 8 inches of joint: YES
Observations (7)
| Distance | Code | Observation |
|---|---|---|
| 403.9 | AMH | H 1526 |
| 42.4 | CM | — |
| 0 | AMH | H 1527 |
| 29.5 | BSV | — |
| 29.5 | FM | — |
| 0 | MWL | — |
| 0 | MWM | — |
Properties (5)
- additional_info
- SC306451
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2016-12-14T00:44:29-08:00
- year_laid
- 39969
