Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Aug 9, 2016, 11:17 AM

  • 08 0275_08 0274 _08092016_042801.mp4

Date
08/09/2016
W/O
580478
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00004
PipeID
P00317
Time
4:17 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K3630
Sewer Name
08 DEL AMO TRUNK
City
CARSON
Loc. details
Main Highway - Suburban/Rural
Location Code
B
Use of Sewer
Sanitary Sewer
District
District 08
Page No.
08
Purpose
Routine Assessment
Project
WO_580478_TV08039_JULY2016
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Width
15 in.
Upstream MH
08 0274
Downstream MH
08 0275
Dir. of Survey
Upstream
Length Surveyed
352.1 ft.
Total Length
352.1 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
2M00
O&M Rating
140
Overall Index
2
Overall Quick
—
Overall Rating
140
Pipe schematic from manhole 08 0274 to 08 0275
MH: 08 0274MH: 08 0275upstream0 ft. AMH - Upstream Manhole, Survey Ends - 08 02750 ft. MGO - General Observation - COCKROACHES IN MANHOLE2.1 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish121.8 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"125.2 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"237.9 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"241.3 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"336.9 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"340.6 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"350.1 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start352.1 ft. MWL - Water Level, 10 %of cross sectional area352.1 ft. MWM - Water Mark, 20 %of cross sectional area352.1 ft. AMH - Downstream Manhole, Survey Begins - 08 0274352.1 ft. MGO - General Observation - COCKROACHES IN MANHOLE

Observation photos (2)

  • General Observation - COCKROACHES IN MANHOLE

    0 ft. - General Observation - COCKROACHES IN MANHOLE

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

All inspections of P00317Work order 580478

Observations (14)

DistanceCodeObservation
0MWL—
2DAGS—
0MWM—
226.9TFC—
352.1AMH08 0275
114.2TFC—
350DAGS—
110.8TFC—
230.3TFC—
352.1MGOCOCKROACHES IN MANHOLE
0AMH08 0274
11.5TFC—
0MGOCOCKROACHES IN MANHOLE
15.2TFC—

Properties (4)

additional_info
SC306064
custom_field_two
4
customer
LACSD
datetime
2016-08-09T04:17:13-07:00
