Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Mar 5, 2018, 10:07 AM

  • H 0049_H 0048_352018_023122.mp4

Date
03/05/2018
W/O
0684704
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00161
PipeID
P10500
Time
2:07 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H0765
Sewer Name
H JOINT OUTFALL H - UNIT 1B
City
SOUTH GATE
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
26
Purpose
Routine Assessment
Project
20180305MDM_JOINT_OUTFALL_H_UNIT_1B
Material
Reinforced Concrete Pipe
Shape
Circular
Height
72.0999984741211 in.
Upstream MH
H 0049
Downstream MH
H 0048
Dir. of Survey
Downstream
Length Surveyed
595.5 ft.
Total Length
595.5 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole H 0049 to H 0048
MH: H 0049MH: H 0048downstream0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. MGO - General Observation - Conn. @ Mh, 3 O' Clock. Active0 ft. AMH - Upstream Manhole, Survey Begins - 2:25AM0 ft. MWM - Water Mark, 20 %of cross sectional area21 ft. MGO - General Observation - 78" RCP FR POLY LINER214.2 ft. MGP - General Photograph - FR POLY LINER220.5 ft. TB - Tap Break-In, at 12 o'clock, -, within 8 inches of joint: YES, 8" - Active256.8 ft. MGO - General Observation - FR POLY LINER306.8 ft. MGO - General Observation - Conn. @ Mh, 3 O' Clock. Active386.7 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: YES, 8" - Active421.8 ft. MGO - General Observation - FR POLY LINER595.5 ft. AMH - Downstream Manhole, Survey Ends - 3:10AM

Observation photos (5)

  • General Observation - 78" RCP FR POLY LINER

    21 ft. - General Observation - 78" RCP FR POLY LINER

  • General Photograph - FR POLY LINER

    214.2 ft. - General Photograph - FR POLY LINER

  • General Observation - FR POLY LINER

    256.8 ft. - General Observation - FR POLY LINER

  • General Observation - Conn. @ Mh, 3 O' Clock. Active

    306.8 ft. - General Observation - Conn. @ Mh, 3 O' Clock. Active

  • General Observation - FR POLY LINER

    421.8 ft. - General Observation - FR POLY LINER

All inspections of P10500Work order 0684704

Observations (12)

DistanceCodeObservation
0MWL—
220.5TBActive
421.8MGOFR POLY LINER
21MGO78" RCP FR POLY LINER
214.2MGPFR POLY LINER
306.8MGOConn. @ Mh, 3 O' Clock. Active
0MGOConn. @ Mh, 3 O' Clock. Active
256.8MGOFR POLY LINER
386.7TBActive
0AMH2:25AM
0MWM—
595.5AMH3:10AM

Properties (6)

custom_field_three
FR POLY LINER GOOD CONDITION
custom_field_two
4
customer
LACSD
datetime
2018-03-05T02:07:21-08:00
lining
FR POLY LINE
year_laid
20040227
