Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Feb 7, 2018, 11:02 AM

  • 04 0072_04 0071 _07022018_031525.mp4

Date
02/07/2018
W/O
685064
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00415
PipeID
P11808
Time
3:02 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5433
Sewer Name
04 SHERMAN TRUNK
City
WEST HOLLYWOOD
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 04
Page No.
03
Purpose
Routine Assessment
Project
WO_685064_TV04009_FEB2018
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Width
15 in.
Upstream MH
04 0072
Downstream MH
04 0071
Dir. of Survey
Downstream
Length Surveyed
269 ft.
Total Length
269 ft.
Structural Index
3
Structural Quick
3B21
Structural Rating
50
O&M Index
2
O&M Quick
2E12
O&M Rating
66
Overall Index
2
Overall Quick
—
Overall Rating
116
Pipe schematic from manhole 04 0072 to 04 0071
MH: 04 0072MH: 04 0071downstream0 ft. MWL - Water Level, 5 %of cross sectional area0 ft. MWM - Water Mark, 5 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 04 00722.9 ft. RFJ - Roots Fine Joint, at 08 o'clock, within 8 inches of joint: YES34.8 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"55.4 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"93.8 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"96.4 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"109.5 ft. DAE - Deposits Attached Encrustation, 5 %of cross sectional area, from 07 to 05 o'clock, , within 8 inches of joint: YES, Start113.1 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start130.1 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"137.5 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"168.3 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"176.1 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"185.6 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish206.9 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"215.2 ft. H - Hole, at 10 o'clock, within 8 inches of joint: NO217.4 ft. RFL - Roots Fine Lateral, at 10 o'clock217.4 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"232.5 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"255.5 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"256.3 ft. FC - Fracture Circumferential, from 09 to 05 o'clock, within 8 inches of joint: YES269 ft. DAE - Deposits Attached Encrustation, 5 %of cross sectional area, from 07 to 05 o'clock, , within 8 inches of joint: YES, Finish269 ft. AMH - Downstream Manhole, Survey Ends - 04 0071

Observation photos (4)

  • Deposits Attached Encrustation, 5 %of cross sectional area, from 07 to 05 o'clock, , within 8 inches of joint: YES, Start

    109.5 ft. - Deposits Attached Encrustation, 5 %of cross sectional area, from 07 to 05 o'clock, , within 8 inches of joint: YES, Start

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    113.1 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Hole, at 10 o'clock, within 8 inches of joint: NO

    215.2 ft. - Hole, at 10 o'clock, within 8 inches of joint: NO

  • Fracture Circumferential, from 09 to 05 o'clock, within 8 inches of joint: YES

    256.3 ft. - Fracture Circumferential, from 09 to 05 o'clock, within 8 inches of joint: YES

All inspections of P11808Work order 685064

Observations (24)

DistanceCodeObservation
0MWL—
96.4TF—
255.5TFC—
34.8TFC—
137.5TF—
130.1TFC—
256.3FC—
269DAE—
176.1TF—
0MWM—
55.4TF—
93.8TF—
113.1CM—
206.9TFC—
109.5DAE—
215.2H—
185.6CM—
168.3TFC—
2.9RFJ—
0AMH04 0072
217.4RFL—
217.4TF—
269AMH04 0071
232.5TF—

Properties (4)

additional_info
SC347071
custom_field_two
1
customer
LACSD
datetime
2018-02-07T03:02:15-08:00
