Wastewater/Activity/PacpInspection/1.0Jan 4, 2018, 09:59 AM
05 0668_05 0667 _04012018_021504.mp4
- Date
- 01/04/2018
- W/O
- 679249
- Weather
- Dry
- Operator/Surveyor
- R.VARGAS
- Sewer ID
- Z00520
- PipeID
- P05895
- Time
- 1:59 AM
- Certificate
- U-209-211
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5306
- Sewer Name
- 05 SOUTH INGLEWOOD-ORANGE AVENUE TRUNK
- City
- INGLEWOOD
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 05
- Page No.
- 10
- Purpose
- Routine Assessment
- Project
- WO_679249_TV05103_JAN2018
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 18 in.
- Width
- 18 in.
- Upstream MH
- 05 0668
- Downstream MH
- 05 0667
- Dir. of Survey
- Downstream
- Length Surveyed
- 372.4 ft.
- Total Length
- 372.4 ft.
- Structural Index
- 1
- Structural Quick
- 1300
- Structural Rating
- 3
- O&M Index
- 2
- O&M Quick
- 2212
- O&M Rating
- 6
- Overall Index
- 1
- Overall Quick
- —
- Overall Rating
- 9
Observation photos (3)
2.1 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
90.9 ft. - Crack Circumferential, from 07 to 09 o'clock, within 8 inches of joint: YES
210.7 ft. - Crack Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES
Observations (20)
| Distance | Code | Observation |
|---|---|---|
| 372.4 | AMH | 05 0667 |
| 0 | MWM | — |
| 90.9 | CC | — |
| 0 | MWL | — |
| 231.8 | RFL | — |
| 283.6 | TFA | — |
| 138 | CC | — |
| 183.2 | TFA | — |
| 210.7 | CC | — |
| 82.6 | TFC | — |
| 134.1 | TFC | — |
| 0 | VC | — |
| 0 | AMH | 05 0668 |
| 372.4 | DAGS | — |
| 0 | MGO | CONNECTION AT MH 3 O'CLOCK ACTIVE |
| 0 | MGO | CONNECTION AT MH 9 O'CLOCK ACTIVE |
| 231.8 | TFA | — |
| 372.4 | MGO | CONNECTION AT MH 3 O'CLOCK ACTIVE |
| 2.1 | DAGS | — |
| 329.4 | TFC | — |
Properties (4)
- additional_info
- SC346475
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2018-01-04T01:59:52-08:00
