Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Sep 29, 2015, 10:36 AM

  • 18 0673_18 0672_29092015_033657.mp4

Date
09/29/2015
W/O
521099
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00696
PipeID
P14522
Time
3:36 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K2691
Sewer Name
18 PHOEBE AVENUE TRUNK
City
LA MIRADA
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 18
Page No.
36
Purpose
Routine Assessment
Project
RFIR_WO_521099_TV18169_AUG2015
Material
Vitrified Clay Pipe
Shape
Circular
Height
18 in.
Upstream MH
18 0672
Downstream MH
18 0673
Dir. of Survey
Upstream
Length Surveyed
204.5 ft.
Total Length
204.5 ft.
Structural Index
3
Structural Quick
3C21
Structural Rating
65
O&M Index
2
O&M Quick
2G00
O&M Rating
80
Overall Index
2
Overall Quick
—
Overall Rating
145
Pipe schematic from manhole 18 0672 to 18 0673
MH: 18 0672MH: 18 0673upstream0 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 3 O'CLOCK0 ft. AMH - Upstream Manhole, Survey Ends - 18 06730 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 9 O'CLOCK1.7 ft. DAE - Deposits Attached Encrustation, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish76.5 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish183.7 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Start189 ft. CL - Crack Longitudinal, at 01 o'clock, within 8 inches of joint: YES202.4 ft. DAE - Deposits Attached Encrustation, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start204.5 ft. AMH - Downstream Manhole, Survey Begins - 18 0672204.5 ft. MWM - Water Mark, 40 %of cross sectional area204.5 ft. MWL - Water Level, 5 %of cross sectional area

Observation photos (1)

  • Deposits Attached Encrustation, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

    2.1 ft. - Deposits Attached Encrustation, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

All inspections of P14522Work order 521099

Observations (11)

DistanceCodeObservation
0AMH18 0672
2.1DAE—
15.5CL—
204.5MGOACTIVE CONNECTION AT MH 3 O'CLOCK
204.5AMH18 0673
128CM—
202.8DAE—
204.5MGOACTIVE CONNECTION AT MH 9 O'CLOCK
0MWM—
0MWL—
20.8CM—

Properties (5)

additional_info
SC203914
custom_field_two
3
customer
LACSD
datetime
2015-09-29T03:36:12-07:00
sewer_category
FACILITY TO FACILITY
