Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 30, 2018, 10:35 AM

  • 29 0256_29 0255 _30012018_025521.mp4

Date
01/30/2018
W/O
685325
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00544
PipeID
P24159
Time
2:35 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5428
Sewer Name
29 WEST HILL STREET TRUNK
City
SIGNAL HILL
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 29
Page No.
03
Purpose
Routine Assessment
Project
WO_685325_TV29112_FEB2018
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
10 in.
Width
10 in.
Upstream MH
29 0256
Downstream MH
29 0255
Dir. of Survey
Downstream
Length Surveyed
421.6 ft.
Total Length
421.6 ft.
Structural Index
3
Structural Quick
413P
Structural Rating
256
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
256
Pipe schematic from manhole 29 0256 to 29 0255
MH: 29 0256MH: 29 0255downstream0 ft. MWL - Water Level, 5 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 29 02560 ft. MWM - Water Mark, 15 %of cross sectional area3.1 ft. FM - Fracture Multiple, from 07 to 03 o'clock, within 8 inches of joint: YES3.9 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: NO, 6"6.2 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES8.9 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start40.2 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"46 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"72.8 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"75.2 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"141.9 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"144.6 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"186.3 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"188.8 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"243.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"245.8 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"269.3 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"272 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"322.9 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"325.6 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"388.8 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"405.4 ft. H - Hole, at 08 o'clock, within 8 inches of joint: YES420.6 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish421.6 ft. AMH - Downstream Manhole, Survey Ends - 29 0255

Observation photos (4)

  • Fracture Multiple, from 07 to 03 o'clock, within 8 inches of joint: YES

    3.1 ft. - Fracture Multiple, from 07 to 03 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

    6.2 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    8.9 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Hole, at 08 o'clock, within 8 inches of joint: YES

    405.4 ft. - Hole, at 08 o'clock, within 8 inches of joint: YES

All inspections of P24159Work order 685325

Observations (25)

DistanceCodeObservation
8.9CM—
186.3TF—
40.2TF—
0MWL—
0AMH29 0256
420.6CM—
46TF—
3.9TB—
141.9TFC—
405.4H—
272TF—
388.8TFC—
0MWM—
421.6AMH29 0255
3.1FM—
325.6TF—
245.8TF—
75.2TFC—
269.3TFC—
188.8TFC—
322.9TFC—
243.1TFC—
6.2CM—
144.6TF—
72.8TFC—

Properties (4)

additional_info
SC347063
custom_field_two
2
customer
LACSD
datetime
2018-01-30T02:35:07-08:00
