Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 16, 2018, 10:53 AM

  • 03 0388_03 MARINA_16012018_025742.mp4

Date
01/16/2018
W/O
679276
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00371
PipeID
P05285
Time
2:53 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5375
Sewer Name
03 MARINA TRUNK, SECTION 2
City
LONG BEACH
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 03
Page No.
25
Purpose
Routine Assessment
Project
WO_679276_TV03135_JAN2018
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
12 in.
Width
12 in.
Upstream MH
03 0388
Downstream MH
03 MARINA
Dir. of Survey
Downstream
Length Surveyed
5 ft.
Total Length
5 ft.
Structural Index
2
Structural Quick
2111
Structural Rating
3
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
2
Overall Quick
—
Overall Rating
3
Pipe schematic from manhole 03 0388 to 03 MARINA
MH: 03 0388MH: 03 MARINAdownstream0 ft. MWM - Water Mark, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 03 03880 ft. MWL - Water Level, 5 %of cross sectional area4 ft. JOM - Joint Offset Medium4 ft. CL - Crack Longitudinal, at 10 o'clock, within 8 inches of joint: YES5 ft. AMH - Downstream Manhole, Survey Ends - 03 MARINA

Observation photos (2)

  • Joint Offset Medium

    4 ft. - Joint Offset Medium

  • Crack Longitudinal, at 10 o'clock, within 8 inches of joint: YES

    4 ft. - Crack Longitudinal, at 10 o'clock, within 8 inches of joint: YES

All inspections of P05285Work order 679276

Observations (6)

DistanceCodeObservation
0MWM—
0AMH03 0388
0MWL—
4JOM—
4CL—
5AMH03 MARINA

Properties (4)

additional_info
SC346953
custom_field_two
3
customer
LACSD
datetime
2018-01-16T02:53:53-08:00
