Wastewater/Activity/PacpInspection/1.0Nov 13, 2017, 07:38 PM
A 0418_A 0417 _13112017_115036.mpg
- Date
- 11/13/2017
- W/O
- 668747
- Weather
- Dry
- Operator/Surveyor
- E RUIZ
- Sewer ID
- Z00322
- PipeID
- P08078
- Time
- 11:38 AM
- Certificate
- 123456
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K5134
- Sewer Name
- A JOA-1A LONG BEACH WRP SLUDGE GRAVITY SEWER
- City
- LONG BEACH
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 19
- Page No.
- 11
- Purpose
- Routine Assessment
- Project
- WO_668747_TV19010_NOV2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 24 in.
- Width
- 24 in.
- Upstream MH
- A 0418
- Downstream MH
- A 0417
- Dir. of Survey
- Downstream
- Length Surveyed
- 112.7 ft.
- Total Length
- 112.7 ft.
- Structural Index
- 3
- Structural Quick
- 3100
- Structural Rating
- 3
- O&M Index
- 3
- O&M Quick
- 4123
- O&M Rating
- 10
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 13
Observation photos (3)
7.1 ft. - Deposits Attached Encrustation, 5 %of cross sectional area, from 09 to 03 o'clock, , within 8 inches of joint: YES, Start
30.3 ft. - Roots Fine Barrell, from 09 to 03 o'clock, within 8 inches of joint: YES, Start
33.8 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 112.7 | AMH | A 0417 |
| 112.7 | MGO | OILE IN CHANNEL |
| 33.8 | FL | — |
| 12.6 | DSZ | SLUDGE |
| 0 | MWM | — |
| 7.1 | DAE | — |
| 0 | MWL | — |
| 30.3 | RFB | — |
| 0 | AMH | A 0418 |
| 112.3 | RFB | — |
| 112.3 | DSZ | — |
| 112.3 | DAE | — |
Properties (4)
- additional_info
- SC348342
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2017-11-13T11:38:02-08:00
