Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 17, 2018, 10:24 AM

  • 19 0217_19 0216_1172018_031858.mp4

Date
01/17/2018
W/O
#
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00718
PipeID
P15186
Time
2:24 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H0726
Sewer Name
19 ARTESIA-CERRITOS TRUNK
City
ARTESIA
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 19
Page No.
04
Purpose
Routine Assessment
Project
20180117MDM_ARTESIA_CERRITOS_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
12 in.
Upstream MH
19 0216
Downstream MH
19 0217
Dir. of Survey
Upstream
Length Surveyed
264.6 ft.
Total Length
264.6 ft.
Structural Index
2
Structural Quick
382C
Structural Rating
62
O&M Index
3
O&M Quick
4121
O&M Rating
6
Overall Index
2
Overall Quick
—
Overall Rating
68
Pipe schematic from manhole 19 0216 to 19 0217
MH: 19 0216MH: 19 0217upstream0 ft. AMH - Upstream Manhole, Survey Ends - 3:35AM0.4 ft. MGO - General Observation - MH CONN 3:00 ACTIVE5 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - H6.4 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SLIGHT6.4 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - H6.4 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - H14.3 ft. FC - Fracture Circumferential, from 10 to 02 o'clock, within 8 inches of joint: YES - H19.7 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped25 ft. FC - Fracture Circumferential, from 01 to 03 o'clock, within 8 inches of joint: YES - H37 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H45.3 ft. FC - Fracture Circumferential, from 11 to 12 o'clock, within 8 inches of joint: YES - H45.3 ft. FL - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES - H57.4 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - H67.3 ft. MWM - Water Mark, 30 %of cross sectional area73.7 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H82.8 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open84.2 ft. FC - Fracture Circumferential, from 01 to 03 o'clock, within 8 inches of joint: YES - SLIGHT88.4 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H101.5 ft. MGO - General Observation - MH CONN 9:00 ACTIVE101.5 ft. MGO - General Observation - UNMAPPED MH108.8 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - H122.4 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped125.2 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open126.5 ft. FC - Fracture Circumferential, from 11 to 01 o'clock, within 8 inches of joint: YES - H148.1 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open149.4 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - H157.5 ft. CL - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H162.7 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open162.7 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 08 to 10 o'clock, , within 8 inches of joint: YES169.4 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open192.9 ft. MGO - General Observation - MH CONN 9:00 ACTIVE192.9 ft. MGO - General Observation - UNMAPPED MH194.7 ft. FC - Fracture Circumferential, from 11 to 01 o'clock, within 8 inches of joint: YES - H199.6 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - H203.3 ft. FC - Fracture Circumferential, from 11 to 12 o'clock, within 8 inches of joint: YES - H210.9 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - H223.2 ft. FC - Fracture Circumferential, from 02 to 03 o'clock, within 8 inches of joint: YES - H228.3 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped246.1 ft. FC - Fracture Circumferential, from 12 to 02 o'clock, within 8 inches of joint: YES - H246.1 ft. FC - Fracture Circumferential, from 02 to 03 o'clock, within 8 inches of joint: YES - H250.3 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - H250.3 ft. FC - Fracture Circumferential, from 09 to 10 o'clock, within 8 inches of joint: YES - H256.6 ft. MGO - General Observation - 12" VCP257.6 ft. FC - Fracture Circumferential, from 02 to 03 o'clock, within 8 inches of joint: YES - HAIRLINE264.6 ft. AMH - Upstream Manhole, Survey Begins - 2:55AM264.6 ft. MWM - Water Mark, 50 %of cross sectional area264.6 ft. MGO - General Observation - MH CONN 3:00 ACTIVE264.6 ft. MWL - Water Level, 10 %of cross sectional area

Observation photos (3)

  • General Observation - 12" VCP

    8 ft. - General Observation - 12" VCP

  • General Observation - UNMAPPED MH

    71.7 ft. - General Observation - UNMAPPED MH

  • General Observation - UNMAPPED MH

    163.1 ft. - General Observation - UNMAPPED MH

All inspections of P15186Work order #

Observations (48)

DistanceCodeObservation
101.9TFOpen
244.9TFCCapped
227.6FLH
239.6FCH
8MGO12" VCP
0AMH2:55AM
180.4FCSLIGHT
36.3TFCCapped
101.9DAGS—
71.7MGOMH CONN 9:00 ACTIVE
116.5TFOpen
107.1CLH
264.2MGOMH CONN 3:00 ACTIVE
0MWM—
250.3FCH
14.3FLH
258.2FCSLIGHT
138.1FCH
190.9FLH
264.6AMH3:35AM
18.5FCH
142.2TFCCapped
115.2FLH
61.3FCH
207.2FCH
95.2TFOpen
0MGOMH CONN 3:00 ACTIVE
14.3FCH
155.8FLH
258.2FCH
69.9FCH
0MWL—
176.2FLH
18.5FCH
259.6FCH
219.3FCH
53.7FLH
219.3FLH
139.4TFOpen
181.8TFOpen
197.3MWM—
65FCH
163.1MGOMH CONN 9:00 ACTIVE
163.1MGOUNMAPPED MH
71.7MGOUNMAPPED MH
258.2FCH
41.4FCH
7FCHAIRLINE

Properties (4)

custom_field_three
HAIRLINE & SLIGHT FRACTURES
custom_field_two
4
customer
LACSD
datetime
2018-01-17T02:24:03-08:00
