Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 16, 2018, 08:38 AM

  • Section#4_H 0117_H 0116__1162018__G6919.mp4

Date
01/16/2018
W/O
0683963
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00165
PipeID
P10568
Time
12:38 AM
Certificate
U-101406022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G6919
Sewer Name
H JOINT OUTFALL H - UNIT 1F
City
HUNTINGTON PARK
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
04
Purpose
Capital Improvement Program Assesment
Project
20180113MDM_JOINT_OUTFALL_H_UNIT_1F
Material
Reinforced Concrete Pipe
Shape
Circular
Height
36 in.
Upstream MH
H 0117
Downstream MH
H 0116
Dir. of Survey
Downstream
Length Surveyed
463.8 ft.
Total Length
463.8 ft.
Structural Index
2
Structural Quick
312P
Structural Rating
169
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
2
Overall Quick
—
Overall Rating
169
Pipe schematic from manhole H 0117 to H 0116
MH: H 0117MH: H 0116downstream0 ft. MWM - Water Mark, 20 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 2:55AM0 ft. MWL - Water Level, 10 %of cross sectional area2 ft. MGO - General Observation - MAG COAT 99% START 8:00 TO 4:0056.8 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - BLISTERING CONCRETE UNDER MAG COAT139.7 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: NO - BLISTERING CONCRETE UNDER MAG COAT288 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: NO - BLISTERING PEELING CONCRETE375.6 ft. MGO - General Observation - 99% MAG COAT458.4 ft. SAV - Surface Aggregate Visible, from 10 to 02 o'clock, within 8 inches of joint: NO - SEVERE AGG SPORATIC463.3 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish - BLISTERING CONCRETE463.3 ft. MGO - General Observation - MAG COAT 99% FINISH463.8 ft. AMH - Downstream Manhole, Survey Ends - 3:25AM

Observation photos (5)

  • General Observation - MAG COAT 99% START 8:00 TO 4:00

    2 ft. - General Observation - MAG COAT 99% START 8:00 TO 4:00

  • Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - BLISTERING CONCRETE UNDER MAG COAT

    56.8 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - BLISTERING CONCRETE UNDER MAG COAT

  • Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: NO - BLISTERING CONCRETE UNDER MAG COAT

    139.7 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: NO - BLISTERING CONCRETE UNDER MAG COAT

  • Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: NO - BLISTERING PEELING CONCRETE

    288 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: NO - BLISTERING PEELING CONCRETE

  • Surface Aggregate Visible, from 10 to 02 o'clock, within 8 inches of joint: NO - SEVERE AGG SPORATIC

    458.4 ft. - Surface Aggregate Visible, from 10 to 02 o'clock, within 8 inches of joint: NO - SEVERE AGG SPORATIC

All inspections of P10568Work order 0683963

Observations (12)

DistanceCodeObservation
0MWM—
463.8AMH3:25AM
0AMH2:55AM
56.8SSSBLISTERING CONCRETE UNDER MAG COAT
463.3SSSBLISTERING CONCRETE
139.7SSSBLISTERING CONCRETE UNDER MAG COAT
2MGOMAG COAT 99% START 8:00 TO 4:00
458.4SAVSEVERE AGG SPORATIC
288SSSBLISTERING PEELING CONCRETE
463.3MGOMAG COAT 99% FINISH
375.6MGO99% MAG COAT
0MWL—

Properties (4)

custom_field_three
BLISTERING CONCRETE-1 AREA SEVERE AGG -99% MAG COA
custom_field_two
3
customer
LACSD
datetime
2018-01-16T00:38:36-08:00
