Wastewater/Activity/PacpInspection/1.0Nov 13, 2017, 10:47 AM
18 0744_18 0743 _13112017_024726.mp4
- Date
- 11/13/2017
- W/O
- 635480
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00706
- PipeID
- P14597
- Time
- 2:47 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5040
- Sewer Name
- 18 SO WHITTIER OUTFALL TR, SECTS 1,2,3,&4
- City
- SANTA FE SPRINGS
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 18
- Page No.
- 26
- Purpose
- Routine Assessment
- Project
- WO_635480_TV18053_NOV2017
- Sewer Type
- Gravity
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 36 in.
- Width
- 36 in.
- Upstream MH
- 18 0744
- Downstream MH
- 18 0743
- Dir. of Survey
- Downstream
- Length Surveyed
- 59 ft.
- Total Length
- 59 ft.
- Structural Index
- 3
- Structural Quick
- 513A
- Structural Rating
- 60
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 60
Observation photos (3)
4.3 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
4.3 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
14.4 ft. - Surface Reinforcement Visible, from 12 to 01 o'clock, within 8 inches of joint: YES
Observations (9)
| Distance | Code | Observation |
|---|---|---|
| 4.3 | SAV | — |
| 0 | MWL | — |
| 58.9 | SSS | — |
| 4.3 | SSS | — |
| 14.4 | SRV | — |
| 58.9 | SAV | — |
| 0 | AMH | 18 0744 |
| 0 | MWM | — |
| 59 | AMH | 18 0743 |
Properties (4)
- additional_info
- SC346265
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2017-11-13T02:47:00-08:00
