Wastewater/Activity/PacpInspection/1.0Sep 21, 2017, 06:53 AM
03 0543_03 0542_20092017_235359.mp4
- Date
- 09/20/2017
- W/O
- 657956
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00367
- PipeID
- P04993
- Time
- 11:53 PM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4885
- Sewer Name
- 03 LOS COYOTES DIAGONAL RELIEF TRUNK
- City
- LAKEWOOD
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 03
- Page No.
- 09
- Purpose
- Routine Assessment
- Project
- WO_657956_TV03153_SEP2017
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 12 in.
- Width
- 12 in.
- Upstream MH
- 03 0543
- Downstream MH
- 03 0542
- Dir. of Survey
- Downstream
- Length Surveyed
- 410 ft.
- Total Length
- 410 ft.
- Structural Index
- 3
- Structural Quick
- 5124
- Structural Rating
- 13
- O&M Index
- 4
- O&M Quick
- 4500
- O&M Rating
- 20
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 33
Observation photos (7)
75.4 ft. - Water Level, Sag in pipe, 5 %of cross sectional area
168.3 ft. - Water Level, Sag in pipe, 15 %of cross sectional area
212.6 ft. - Camera Underwater, Start
246.9 ft. - Water Level, Sag in pipe, 15 %of cross sectional area
299.9 ft. - Water Level, Sag in pipe, 20 %of cross sectional area
305.7 ft. - Camera Underwater, Start
404.8 ft. - Broken, from 08 to 04 o'clock, within 8 inches of joint: YES
Observations (14)
| Distance | Code | Observation |
|---|---|---|
| 75.4 | MWLS | — |
| 212.6 | MCU | — |
| 332.7 | MCU | — |
| 410 | AMH | 03 0542 |
| 168.3 | MWLS | — |
| 0 | MWL | — |
| 246.9 | MWLS | — |
| 299.9 | MWLS | — |
| 0 | MWM | — |
| 0 | MGO | CONNECTION AT MH 9 O'CLOCK |
| 228.1 | MCU | — |
| 0 | AMH | 03 0543 |
| 404.8 | B | — |
| 305.7 | MCU | — |
Properties (6)
- additional_info
- SC345945
- custom_field_two
- 1
- customer
- LACSD
- datetime
- 2017-09-20T23:53:50-07:00
- sewer_category
- Gravity
- year_laid
- 30845
