Wastewater/Activity/PacpInspection/1.0Oct 23, 2017, 12:09 PM
02 1361_02 1360 _23102017_051952.mp4
- Date
- 10/23/2017
- W/O
- 668762
- Weather
- Dry
- Operator/Surveyor
- JUAN B
- Sewer ID
- Z00277
- PipeID
- P03884
- Time
- 5:09 AM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K4998
- Sewer Name
- 02 JANE STREET BRANCH TRUNK
- City
- LOS ANGELES
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 11A
- Purpose
- Routine Assessment
- Project
- WO_668762_TV02342_NOV2017
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 12 in.
- Width
- 12 in.
- Upstream MH
- 02 1360
- Downstream MH
- 02 1361
- Dir. of Survey
- Upstream
- Length Surveyed
- 265.5 ft.
- Total Length
- 265.5 ft.
- Structural Index
- 3
- Structural Quick
- 3100
- Structural Rating
- 3
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 5
Observation photos (2)
3.3 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
5.9 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (13)
| Distance | Code | Observation |
|---|---|---|
| 3.3 | DAGS | — |
| 265.5 | AMH | 02 1361 |
| 92.4 | TF | — |
| 264 | DAGS | — |
| 35.3 | TF | — |
| 187.6 | TF | — |
| 157.6 | TF | — |
| 5.9 | CM | — |
| 0 | MWL | — |
| 0 | MWM | — |
| 241.2 | TF | — |
| 264 | CM | — |
| 0 | AMH | 02 1360 |
Properties (5)
- additional_info
- SC350352
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-10-23T05:09:11-07:00
- sewer_category
- Gravity
