Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 31, 2017, 07:29 AM

  • 18 0611_18 1253 __31102017_003059.mp4

Date
10/31/2017
W/O
668742
Weather
Dry
Operator/Surveyor
JUAN B
Sewer ID
Z00688
PipeID
P26361
Time
12:29 AM
Certificate
U-715-07000770
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K5162
Sewer Name
18 MARQUARDT AVENUE TRUNK
City
SANTA FE SPRINGS
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 18
Page No.
35
Purpose
Routine Assessment
Project
WO_668742_TV18028_NOV2017
Material
Vitrified Clay Pipe
Shape
Circular
Height
21 in.
Width
21 in.
Upstream MH
18 0611
Downstream MH
18 1253
Dir. of Survey
Downstream
Length Surveyed
91.3 ft.
Total Length
91.3 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
2211
O&M Rating
5
Overall Index
2
Overall Quick
—
Overall Rating
5
Pipe schematic from manhole 18 0611 to 18 1253
MH: 18 0611MH: 18 1253downstream0 ft. MGO - General Observation - MH 18 0611 ABANDONED0 ft. AMH - Upstream Manhole, Survey Begins - 18 06110 ft. MWM - Water Mark, 35 %of cross sectional area0 ft. MWL - Water Level, 30 %of cross sectional area3.3 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start31.7 ft. LL - Alignment Left, 5 %49.4 ft. DSC - Deposits Settled Compacted, 10 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start90.2 ft. DSC - Deposits Settled Compacted, 10 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Finish90.2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish91.3 ft. MGO - General Observation - CONNECTION AT 3 OC91.3 ft. AMH - Downstream Manhole, Survey Ends - 18 1253

Observation photos (2)

  • General Observation - MH 18 0611 ABANDONED

    0 ft. - General Observation - MH 18 0611 ABANDONED

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    3.3 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

All inspections of P26361Work order 668742

Observations (11)

DistanceCodeObservation
91.3MGOCONNECTION AT 3 OC
91.3AMH18 1253
0MGOMH 18 0611 ABANDONED
3.3DAGS—
90.2DSC—
31.7LL—
0AMH18 0611
90.2DAGS—
0MWM—
0MWL—
49.4DSC—

Properties (6)

additional_info
SC350362
custom_field_two
4
customer
LACSD
datetime
2017-10-31T00:29:38-07:00
sewer_category
Gravity
year_laid
41334
