Wastewater/Activity/PacpInspection/1.0Oct 20, 2017, 07:21 AM
16 0348_16 0347 _20102017_002127.mp4
- Date
- 10/20/2017
- W/O
- 663187
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00665
- PipeID
- P13399
- Time
- 12:21 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5033
- Sewer Name
- 16 SAN MARINO OUTFALL TRUNK
- City
- SAN MARINO
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 16
- Page No.
- 17
- Purpose
- Routine Assessment
- Project
- WO_663187_TV16060_OCT2017
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 18 in.
- Width
- 18 in.
- Upstream MH
- 16 0347
- Downstream MH
- 16 0348
- Dir. of Survey
- Upstream
- Length Surveyed
- 198.7 ft.
- Total Length
- 198.7 ft.
- Structural Index
- 3
- Structural Quick
- 3G00
- Structural Rating
- 117
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 117
Observation photos (2)
5.8 ft. - Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES
8.3 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 0 | AMH | 16 0347 |
| 8.3 | CM | — |
| 198.7 | CM | — |
| 0 | MGO | CONNECTION AT MH 9 O'CLOCK |
| 0 | MWL | — |
| 5.8 | CM | — |
| 0 | MWM | — |
| 198.7 | AMH | 16 0348 |
| 134.2 | TFC | — |
| 65.8 | TFC | — |
Properties (5)
- additional_info
- SC346196
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-10-20T00:21:12-07:00
- sewer_category
- Gravity
