Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 3, 2017, 10:00 AM

  • 29 0180_29 0179 _03102017_030144.mp4

Date
10/03/2017
W/O
663248
Weather
Dry
Operator/Surveyor
K. ADAME
Sewer ID
Z00354
PipeID
P24076
Time
3:00 AM
Certificate
07009000
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4817
Sewer Name
29 28TH STREET TRUNK
City
SIGNAL HILL
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 29
Page No.
01
Purpose
Routine Assessment
Project
WO_663248_TV29052_OCT2017
Material
Vitrified Clay Pipe
Shape
Circular
Height
12 in.
Width
12 in.
Upstream MH
29 0180
Downstream MH
29 0179
Dir. of Survey
Downstream
Length Surveyed
380.8 ft.
Total Length
380.8 ft.
Structural Index
3
Structural Quick
423B
Structural Rating
47
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
47
Pipe schematic from manhole 29 0180 to 29 0179
MH: 29 0180MH: 29 0179downstream0 ft. MWM - Water Mark, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 29 01800 ft. MWL - Water Level, 5 %of cross sectional area5.9 ft. CM - Crack Multiple, from 09 to 01 o'clock, within 8 inches of joint: YES9.1 ft. CM - Crack Multiple, from 12 to 03 o'clock, within 8 inches of joint: YES15 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES38.8 ft. CM - Crack Multiple, from 10 to 03 o'clock, within 8 inches of joint: YES45.1 ft. CM - Crack Multiple, from 10 to 03 o'clock, within 8 inches of joint: YES60.3 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES63.3 ft. FL - Fracture Longitudinal, at 11 o'clock, within 8 inches of joint: YES69.4 ft. CM - Crack Multiple, from 10 to 01 o'clock, within 8 inches of joint: YES72.2 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Start80.8 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6"83.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6"213.4 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"216.1 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"300.1 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish300.3 ft. FL - Fracture Longitudinal, at 11 o'clock, within 8 inches of joint: YES301.9 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: NO, Start315.3 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: NO, Finish315.3 ft. FM - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES320.8 ft. CM - Crack Multiple, from 09 to 12 o'clock, within 8 inches of joint: YES326.6 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: NO, Start334.3 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6"336.3 ft. FM - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: NO, Start336.3 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: NO, Finish337.4 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"367.9 ft. FM - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: NO, Finish380.8 ft. AMH - Downstream Manhole, Survey Ends - 29 0179

Observation photos (15)

  • Crack Multiple, from 09 to 01 o'clock, within 8 inches of joint: YES

    5.9 ft. - Crack Multiple, from 09 to 01 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 12 to 03 o'clock, within 8 inches of joint: YES

    9.1 ft. - Crack Multiple, from 12 to 03 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

    15 ft. - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 10 to 03 o'clock, within 8 inches of joint: YES

    38.8 ft. - Crack Multiple, from 10 to 03 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 10 to 03 o'clock, within 8 inches of joint: YES

    45.1 ft. - Crack Multiple, from 10 to 03 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

    60.3 ft. - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

  • Fracture Longitudinal, at 11 o'clock, within 8 inches of joint: YES

    63.3 ft. - Fracture Longitudinal, at 11 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 10 to 01 o'clock, within 8 inches of joint: YES

    69.4 ft. - Crack Multiple, from 10 to 01 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

    72.2 ft. - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

  • Fracture Longitudinal, at 11 o'clock, within 8 inches of joint: YES

    300.3 ft. - Fracture Longitudinal, at 11 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: NO, Start

    301.9 ft. - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: NO, Start

  • Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

    315.3 ft. - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 09 to 12 o'clock, within 8 inches of joint: YES

    320.8 ft. - Crack Multiple, from 09 to 12 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: NO, Start

    326.6 ft. - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: NO, Start

  • Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: NO, Start

    336.3 ft. - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: NO, Start

All inspections of P24076Work order 663248

Observations (29)

DistanceCodeObservation
337.4TFC—
69.4CM—
367.9FM—
213.4TFC—
63.3FL—
380.8AMH29 0179
38.8CM—
0MWM—
300.3FL—
216.1TFC—
326.6CM—
300.1CM—
315.3CM—
0AMH29 0180
336.3FM—
72.2CM—
15CM—
5.9CM—
0MWL—
83.1TFC—
336.3CM—
60.3CM—
334.3TF—
45.1CM—
9.1CM—
301.9CM—
315.3FM—
80.8TF—
320.8CM—

Properties (5)

additional_info
SC353066
custom_field_two
3
customer
LACSD
datetime
2017-10-03T03:00:53-07:00
sewer_category
Gravity
