03 0070_03 0069_15082017_160228.mp4
- Date
- 07/27/2017
- W/O
- 1590881
- Weather
- Dry
- Operator/Surveyor
- M.MARTINEZ
- Sewer ID
- Z00366
- PipeID
- P05091
- Time
- 12:12 PM
- Certificate
- U-115-06022794
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K3993
- Sewer Name
- 03 LOS COYOTES DIAGONAL TRUNK
- City
- CERRITOS
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 03
- Page No.
- 05
- Purpose
- Routine Assessment
- Project
- WO_646534_TV03011_JUL2017
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 03 0070
- Downstream MH
- 03 0069
- Dir. of Survey
- Downstream
- Length Surveyed
- 265.4 ft.
- Total Length
- 265.4 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 2
- O&M Quick
- 2J00
- O&M Rating
- 112
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 112
Observation photos (7)
3.1 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
3.1 ft. - Deposits Attached Encrustation, 10 %of cross sectional area, from 08 to 04 o'clock, , within 8 inches of joint: YES
34.1 ft. - Deposits Attached Encrustation, 10 %of cross sectional area, from 08 to 04 o'clock, , within 8 inches of joint: YES
54.1 ft. - Deposits Attached Encrustation, 10 %of cross sectional area, from 08 to 04 o'clock, , within 8 inches of joint: YES
178.1 ft. - Deposits Attached Encrustation, 10 %of cross sectional area, from 08 to 04 o'clock, , within 8 inches of joint: YES
258.1 ft. - Material Change, Transite
262 ft. - Material Change, Vitrified clay pipe
Observations (15)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWL | — |
| 3.1 | DAGS | — |
| 70 | TB | — |
| 178.1 | DAE | — |
| 34.1 | DAE | — |
| 0 | MWM | — |
| 262 | MMC | — |
| 0 | AMH | 03 0070 |
| 262 | DAGS | — |
| 258.1 | MMC | — |
| 265.4 | AMH | 03 0069 |
| 265 | MGO | CONNECTION AT MH 9 O'CLOCK |
| 175.1 | TB | — |
| 3.1 | DAE | — |
| 54.1 | DAE | — |
Properties (5)
- additional_info
- SC345560
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2017-07-27T12:12:26-07:00
- sewer_category
- Gravity
