Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Dec 5, 2017, 06:09 PM

  • 02 1390_A 0822_1252017_111054.mp4

Date
12/05/2017
W/O
0647477
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z00323
PipeID
P08163
Time
10:09 AM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7573
Sewer Name
A JOA-1A LOS COYOTES WRP INTERCEPTOR
City
BELL GARDENS
Loc. details
Other
Location Code
Z
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
26
Purpose
Routine Assessment
Project
20171205DF_JOA_1A_LOS_COYOTES_WRP_INTERCEPTOR
Material
Reinforced Concrete Pipe
Shape
Circular
Height
56.790000915527344 in.
Upstream MH
02 1390
Downstream MH
A 0822
Dir. of Survey
Downstream
Length Surveyed
489.3 ft.
Total Length
489.3 ft.
Structural Index
2
Structural Quick
2100
Structural Rating
2
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
2
Overall Quick
—
Overall Rating
2
Pipe schematic from manhole 02 1390 to A 0822
MH: 02 1390MH: A 0822downstream0 ft. AMH - Upstream Manhole, Survey Begins - 11:00 AM0.1 ft. MWL - Water Level, 25 %of cross sectional area0.1 ft. MWM - Water Mark, 30 %of cross sectional area2 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start15.7 ft. MGP - General Photograph64.6 ft. MGP - General Photograph81.9 ft. MGP - General Photograph - SEAM TAPE PEELING100.1 ft. MGP - General Photograph191.9 ft. MGP - General Photograph266.5 ft. MGP - General Photograph435 ft. MGP - General Photograph - SEAM TAPE441.3 ft. MGP - General Photograph487.9 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish489.3 ft. AMH - Downstream Manhole, Survey Ends - 11:47 AM

Observation photos (8)

  • Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    2 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • General Photograph

    15.7 ft. - General Photograph

  • General Photograph - SEAM TAPE PEELING

    81.9 ft. - General Photograph - SEAM TAPE PEELING

  • General Photograph

    100.1 ft. - General Photograph

  • General Photograph

    191.9 ft. - General Photograph

  • General Photograph

    266.5 ft. - General Photograph

  • General Photograph - SEAM TAPE

    435 ft. - General Photograph - SEAM TAPE

  • General Photograph

    441.3 ft. - General Photograph

All inspections of P08163Work order 0647477

Observations (14)

DistanceCodeObservation
0AMH11:00 AM
64.6MGP—
266.5MGP—
0.1MWL—
435MGPSEAM TAPE
489.3AMH11:47 AM
441.3MGP—
100.1MGP—
81.9MGPSEAM TAPE PEELING
2SSS—
0.1MWM—
191.9MGP—
15.7MGP—
487.9SSS—

Properties (4)

custom_field_two
4
customer
LACSD
datetime
2017-12-05T10:09:44-08:00
year_laid
20110907
