Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Sep 27, 2017, 07:12 AM

  • B 1194_B 1193_27092017_001251.mp4

Date
09/27/2017
W/O
663486
Weather
Dry
Operator/Surveyor
R.VARGAS
Sewer ID
Z01125
PipeID
P13514
Time
12:12 AM
Certificate
U-209-211
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4278
Sewer Name
B JOINT OUTFALL B - UNIT 6H
City
S.PASADENA
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
16
Purpose
Routine Assessment
Project
WO_663486_TV16065_OCT2017
Material
Vitrified Clay Pipe
Shape
Circular
Height
27 in.
Width
27 in.
Upstream MH
B 1194
Downstream MH
B 1193
Dir. of Survey
Downstream
Length Surveyed
248.9 ft.
Total Length
248.9 ft.
Structural Index
2
Structural Quick
2200
Structural Rating
4
O&M Index
2
O&M Quick
2M00
O&M Rating
138
Overall Index
2
Overall Quick
—
Overall Rating
142
Pipe schematic from manhole B 1194 to B 1193
MH: B 1194MH: B 1193downstream0 ft. MWM - Water Mark, 25 %of cross sectional area0 ft. MWL - Water Level, 20 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - B 11942.1 ft. DAGS - Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start18 ft. FC - Fracture Circumferential, from 07 to 09 o'clock, within 8 inches of joint: YES33.4 ft. DAE - Deposits Attached Encrustation, 5 %of cross sectional area, from 08 to 02 o'clock, , within 8 inches of joint: YES121.6 ft. CL - Crack Longitudinal, at 10 o'clock, within 8 inches of joint: YES138.6 ft. DAE - Deposits Attached Encrustation, 5 %of cross sectional area, from 08 to 04 o'clock, , within 8 inches of joint: YES, Start234.8 ft. DAE - Deposits Attached Encrustation, 5 %of cross sectional area, from 08 to 04 o'clock, , within 8 inches of joint: YES, Finish245.8 ft. DAGS - Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish248.9 ft. AMH - Downstream Manhole, Survey Ends - B 1193

Observation photos (5)

  • Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2.1 ft. - Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Fracture Circumferential, from 07 to 09 o'clock, within 8 inches of joint: YES

    18 ft. - Fracture Circumferential, from 07 to 09 o'clock, within 8 inches of joint: YES

  • Deposits Attached Encrustation, 5 %of cross sectional area, from 08 to 02 o'clock, , within 8 inches of joint: YES

    33.4 ft. - Deposits Attached Encrustation, 5 %of cross sectional area, from 08 to 02 o'clock, , within 8 inches of joint: YES

  • Crack Longitudinal, at 10 o'clock, within 8 inches of joint: YES

    121.6 ft. - Crack Longitudinal, at 10 o'clock, within 8 inches of joint: YES

  • Deposits Attached Encrustation, 5 %of cross sectional area, from 08 to 04 o'clock, , within 8 inches of joint: YES, Start

    138.6 ft. - Deposits Attached Encrustation, 5 %of cross sectional area, from 08 to 04 o'clock, , within 8 inches of joint: YES, Start

All inspections of P13514Work order 663486

Observations (11)

DistanceCodeObservation
0MWM—
18FC—
138.6DAE—
248.9AMHB 1193
0MWL—
121.6CL—
0AMHB 1194
245.8DAGS—
234.8DAE—
33.4DAE—
2.1DAGS—

Properties (5)

additional_info
SC352125
custom_field_two
3
customer
LACSD
datetime
2017-09-27T00:12:13-07:00
sewer_category
Gravity
