Wastewater/Activity/PacpInspection/1.0Sep 29, 2017, 04:41 AM
- Date
- 09/28/2017
- W/O
- 657962
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00012
- PipeID
- P00347
- Time
- 9:41 PM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4892
- Sewer Name
- 08 JAMES STREET TRUNK
- City
- TORRANCE
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 08
- Page No.
- 07
- Purpose
- Routine Assessment
- Project
- WO_630370_TV05315_AUG2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 8 in.
- Width
- 8 in.
- Upstream MH
- 08 0300A
- Downstream MH
- 08 0301
- Dir. of Survey
- Upstream
- Length Surveyed
- 43.9 ft.
- Total Length
- 43.9 ft.
- Structural Index
- 3
- Structural Quick
- 4138
- Structural Rating
- 28
- O&M Index
- 1
- O&M Quick
- 1200
- O&M Rating
- 2
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 30
Observation photos (5)
3.2 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES
3.2 ft. - Roots Fine Joint, at 09 o'clock, within 8 inches of joint: YES
5.6 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
32.1 ft. - Fracture Multiple, from 07 to 05 o'clock, within 8 inches of joint: YES
33.5 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (14)
| Distance | Code | Observation |
|---|---|---|
| 43.9 | MGO | CONNECTION AT MH 9 O'CLOCK |
| 0 | MWM | — |
| 0 | MWL | — |
| 0 | AMH | 08 0300A |
| 0 | MGO | CONNECTION AT MH 3 O'CLOCK |
| 5.6 | RFJ | — |
| 43.9 | AMH | 08 0301 |
| 32.1 | FM | — |
| 43 | CM | — |
| 3.2 | CM | — |
| 32.1 | CM | — |
| 3.2 | RFJ | — |
| 33.5 | CM | — |
| 5.6 | CM | — |
Properties (4)
- additional_info
- SC346152
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2017-09-28T21:41:27-07:00
