Wastewater/Activity/PacpInspection/1.0Dec 8, 2015, 10:38 AM
- Date
- 12/08/2015
- W/O
- 531059
- Weather
- Dry
- Operator/Surveyor
- R.VARGAS
- Sewer ID
- Z00664
- PipeID
- P13674
- Time
- 2:38 AM
- Certificate
- U-209-211
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K2842
- Sewer Name
- 16 PASADENA EAST-WEST INTERCEPTOR TRUNK
- City
- PASADENA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 16
- Page No.
- 09
- Purpose
- Routine Assessment
- Project
- WO_531059_TV16030_OCT2015
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 30 in.
- Upstream MH
- 16 0622A
- Downstream MH
- 16 0623
- Dir. of Survey
- Upstream
- Length Surveyed
- 44.2 ft.
- Total Length
- 44.2 ft.
- Structural Index
- 3
- Structural Quick
- 3800
- Structural Rating
- 24
- O&M Index
- 2
- O&M Quick
- 2812
- O&M Rating
- 18
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 42
Observation photos (2)
2.2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
2.2 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (14)
| Distance | Code | Observation |
|---|---|---|
| 2.2 | MGO | MAGNEZIUM H.O. START |
| 44.2 | VC | — |
| 41.5 | MGO | MAGNEZIUM H.O. FINISH |
| 2.2 | DAGS | — |
| 41.6 | SAV | — |
| 0 | MWL | — |
| 44.2 | MGO | LATERAL AT MH 3 OCLOCK ACTIVE |
| 0 | VC | — |
| 0 | AMH | 16 0622A |
| 0 | MWM | — |
| 44.2 | AMH | 16 0623 |
| 2.2 | SAV | — |
| 0 | MGO | LATERAL AT MH 3 OCLOCK ACTIVE |
| 41.6 | DAGS | — |
Properties (5)
- additional_info
- SC205696
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2015-12-08T02:38:22-08:00
- sewer_category
- GRAVITY
