Wastewater/Activity/PacpInspection/1.0Apr 29, 2016, 09:53 AM
15 0258_15 0257A_20160429_030826.mp4
- Date
- 04/29/2016
- W/O
- 568734
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00627
- PipeID
- P12181
- Time
- 2:53 AM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K3334
- Sewer Name
- 15 SAN JOSE CREEK TRUNK
- City
- LA PUENTE
- Loc. details
- Easement/Right of Way
- Location Code
- D
- Use of Sewer
- Sanitary Sewer
- District
- District 15
- Page No.
- 34
- Purpose
- Routine Assessment
- Project
- WO_568734_TV15001_MAY2016
- Sewer Type
- GRAVITY
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 18 in.
- Upstream MH
- 15 0257A
- Downstream MH
- 15 0258
- Dir. of Survey
- Upstream
- Length Surveyed
- 387.8 ft.
- Total Length
- 387.8 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 2
- O&M Quick
- 2200
- O&M Rating
- 4
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 4
Observation photos (3)
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
387.7 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish
387.8 ft. - General Observation - COCKROACHES IN MANHOLE
Observations (14)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWL | — |
| 190.8 | TFC | — |
| 387.8 | MGO | COCKROACHES IN MANHOLE |
| 2 | DAGS | — |
| 0 | MWM | — |
| 0 | AMH | 15 0257A |
| 0 | MGO | COCKROACHES IN MANHOLE |
| 289.2 | TFC | — |
| 387.8 | AMH | 15 0258 |
| 34.8 | TFC | — |
| 84.8 | TFC | — |
| 0 | MGO | ACXTIVE CONNECTION AT MH 9 O'CLOCK |
| 2 | MGO | MAG COATING 80% |
| 387.7 | DAGS | — |
Properties (4)
- additional_info
- SC305608
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2016-04-29T02:53:13-07:00
