Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Aug 29, 2017, 10:19 AM

  • 30 0359_30 0358 _29082017_034836.mp4

Date
08/29/2017
W/O
652021
Weather
Dry
Operator/Surveyor
KYLE A.
Sewer ID
Z00854
PipeID
P17995
Time
3:19 AM
Certificate
07009000
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4807
Sewer Name
30 CLIFTON P.P. FORCE MAIN GRAVITY TRUNK
City
REDONDO BEACH
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 30
Page No.
07
Purpose
Routine Assessment
Project
WO_652021_TV30011_AUG2017
Material
Vitrified Clay Pipe
Shape
Circular
Height
10 in.
Width
10 in.
Upstream MH
30 0358
Downstream MH
30 0359
Dir. of Survey
Upstream
Length Surveyed
259.1 ft.
Total Length
259.1 ft.
Structural Index
3
Structural Quick
5134
Structural Rating
25
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
25
Pipe schematic from manhole 30 0358 to 30 0359
MH: 30 0358MH: 30 0359upstream0 ft. AMH - Upstream Manhole, Survey Ends - 30 035923 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: NO, 6"99 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish143.9 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start148 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES160 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES172 ft. CL - Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES184 ft. B - Broken, from 09 to 02 o'clock, within 8 inches of joint: YES194 ft. CL - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES199.1 ft. CL - Crack Longitudinal, at 10 o'clock, within 8 inches of joint: YES205.1 ft. CL - Crack Longitudinal, at 08 o'clock, within 8 inches of joint: YES212 ft. CM - Crack Multiple, from 02 to 03 o'clock, within 8 inches of joint: YES259.1 ft. AMH - Downstream Manhole, Survey Begins - 30 0358259.1 ft. MWL - Water Level, 5 %of cross sectional area259.1 ft. MWM - Water Mark, 10 %of cross sectional area

Observation photos (9)

  • Crack Multiple, from 02 to 03 o'clock, within 8 inches of joint: YES

    47.1 ft. - Crack Multiple, from 02 to 03 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 08 o'clock, within 8 inches of joint: YES

    54 ft. - Crack Longitudinal, at 08 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 10 o'clock, within 8 inches of joint: YES

    60 ft. - Crack Longitudinal, at 10 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

    65.1 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

  • Broken, from 09 to 02 o'clock, within 8 inches of joint: YES

    75.1 ft. - Broken, from 09 to 02 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES

    87.1 ft. - Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

    99.1 ft. - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

    111.1 ft. - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    115.2 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

All inspections of P17995Work order 652021

Observations (15)

DistanceCodeObservation
236.1TB—
65.1CL—
99.1CM—
259.1AMH30 0359
111.1CM—
75.1B—
47.1CM—
0AMH30 0358
54CL—
0MWL—
115.2CM—
160.1CM—
87.1CL—
60CL—
0MWM—

Properties (5)

additional_info
SC353038
custom_field_two
1
customer
LACSD
datetime
2017-08-29T03:19:39-07:00
sewer_category
Gravity
