Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Aug 31, 2017, 09:44 AM

  • 01 1213_01 1212_31082017_024558.mp4

Date
08/31/2017
W/O
630377
Weather
Dry
Operator/Surveyor
CORTEZ ESTEBAN
Sewer ID
Z00226
PipeID
P02125
Time
2:44 AM
Certificate
U-209-8148
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4910
Sewer Name
01 WILCOX AVENUE TRUNK, EXTENSION #1
City
CUDAHY
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
08
Purpose
Routine assessment
Project
wilcox
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Width
15 in.
Upstream MH
01 1212
Downstream MH
01 1213
Dir. of Survey
Upstream
Length Surveyed
201.9 ft.
Total Length
201.9 ft.
Structural Index
2
Structural Quick
2400
Structural Rating
8
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
2
Overall Quick
—
Overall Rating
8
Pipe schematic from manhole 01 1212 to 01 1213
MH: 01 1212MH: 01 1213upstream0 ft. AMH - Upstream Manhole, Survey Ends - 01 12134.7 ft. CL - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Finish15.8 ft. CL - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start53.6 ft. CL - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES76.2 ft. CL - Crack Longitudinal, at 11 o'clock, within 8 inches of joint: YES, Finish110 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: YES, 4"111.8 ft. CL - Crack Longitudinal, at 11 o'clock, within 8 inches of joint: YES, Start116.2 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 4"147.4 ft. CL - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES170.6 ft. TBA - Tap Break-In Active, at 11 o'clock, -, within 8 inches of joint: YES, 4"201.9 ft. AMH - Downstream Manhole, Survey Begins - 01 1212201.9 ft. MGO - General Observation - SERVICE CONNECTION AT 9 O'CLOCK AT MH201.9 ft. MWM - Water Mark, 35 %of cross sectional area201.9 ft. MGO - General Observation - SERVICE CONNECTION AT 3 O' CLOCK AT MH201.9 ft. MWL - Water Level, 25 %of cross sectional area

Observation photos (4)

  • Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

    54.5 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 11 o'clock, within 8 inches of joint: YES, Start

    90.1 ft. - Crack Longitudinal, at 11 o'clock, within 8 inches of joint: YES, Start

  • Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

    148.3 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start

    186.1 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start

All inspections of P02125Work order 630377

Observations (15)

DistanceCodeObservation
197.2CL—
54.5CL—
148.3CL—
186.1CL—
0AMH01 1212
0MGOSERVICE CONNECTION AT 9 O'CLOCK AT MH
91.9TF—
85.7TF—
0MWM—
31.3TBA—
125.7CL—
0MGOSERVICE CONNECTION AT 3 O' CLOCK AT MH
201.9AMH01 1213
90.1CL—
0MWL—

Properties (5)

additional_info
SC345816
custom_field_two
4
customer
LACSD
datetime
2017-08-31T02:44:44-07:00
sewer_category
Gravity
