Wastewater/Activity/PacpInspection/1.0Aug 31, 2017, 06:01 AM
05 1389_05 1388 _30082017_230156.mp4
- Date
- 08/30/2017
- W/O
- 652020
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00487
- PipeID
- P06609
- Time
- 11:01 PM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4804
- Sewer Name
- 05 MONETA TRUNK
- City
- GARDENA
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 05
- Page No.
- 21
- Purpose
- Routine Assessment
- Project
- WO_652020_TV05074_AUG2017
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 10 in.
- Width
- 10 in.
- Upstream MH
- 05 1388
- Downstream MH
- 05 1389
- Dir. of Survey
- Upstream
- Length Surveyed
- 336 ft.
- Total Length
- 336.1 ft.
- Structural Index
- 3
- Structural Quick
- 3L00
- Structural Rating
- 198
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 200
Observation photos (2)
4.6 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
235.9 ft. - Deposits Attached Grease, 10 %of cross sectional area, from 07 to 05 o'clock, , within 8 inches of joint: YES
Observations (16)
| Distance | Code | Observation |
|---|---|---|
| 47.4 | TF | — |
| 0 | MWL | — |
| 192.1 | TF | — |
| 4.6 | CM | — |
| 238.1 | TFA | — |
| 63.1 | TFC | — |
| 327.2 | TFA | — |
| 0 | MGO | CONNECTION AT MH 9 O'CLOCK CAPPED |
| 0 | MWM | — |
| 235.9 | DAGS | — |
| 336.1 | CM | — |
| 336.1 | AMH | 05 1389 |
| 0 | MGO | CONNECTION AT MH 3 O'CLOCK |
| 0 | AMH | 05 1388 |
| 136.6 | TF | — |
| 210.7 | TF | — |
Properties (5)
- additional_info
- SC345913
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-08-30T23:01:22-07:00
- sewer_category
- Gravity
