Wastewater/Activity/PacpInspection/1.0Jul 6, 2017, 08:23 AM
05 0954_05 0953A _06072017_022610.mpg
- Date
- 07/06/2017
- W/O
- 630086
- Weather
- Dry
- Operator/Surveyor
- JUAN B
- Sewer ID
- Z00481
- PipeID
- P23595
- Time
- 1:23 AM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K4552
- Sewer Name
- 05 MANCHESTER AVENUE PUMP TRUNK
- City
- HAWTHORNE
- Loc. details
- Railway
- Location Code
- L
- Use of Sewer
- Sanitary Sewer
- District
- District 05
- Page No.
- 14
- Purpose
- Routine Assessment
- Project
- WO_630086_TV05069_JUN2017
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 18 in.
- Width
- 18 in.
- Upstream MH
- 05 0953A
- Downstream MH
- 05 0954
- Dir. of Survey
- Upstream
- Length Surveyed
- 138.9 ft.
- Total Length
- 138.9 ft.
- Structural Index
- 3
- Structural Quick
- 3121
- Structural Rating
- 5
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 7
Observation photos (3)
3.2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
4.5 ft. - Crack Longitudinal, at 08 o'clock, within 8 inches of joint: YES
13.4 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWM | — |
| 138.9 | DAGS | — |
| 4.5 | CL | — |
| 0 | MWL | — |
| 3.2 | DAGS | — |
| 0 | AMH | 05 0953A |
| 138.9 | CM | — |
| 138.9 | MGO | CAPPED CONNECTION AT 9 OC |
| 13.4 | CM | — |
| 138.9 | AMH | 05 0954 |
Properties (5)
- additional_info
- SC345383
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-07-06T01:23:30-07:00
- sewer_category
- Gravity
