Wastewater/Activity/PacpInspection/1.0Sep 1, 2017, 11:31 AM
01 0120A_01 0120_912017_051128.mp4
- Date
- 09/01/2017
- W/O
- 0657949
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z00203
- PipeID
- P01188
- Time
- 4:31 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H0634
- Sewer Name
- 01 COMPTON CREEK EXTENSION TRUNK, SECTION 1
- City
- COMPTON
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 01
- Page No.
- 12
- Purpose
- Maintenance Related
- Project
- 20170901MDM_COMPTON_CREEK_EXTENSION_TRUNK_SECTION_1
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 12 in.
- Upstream MH
- 01 0120
- Downstream MH
- 01 0120A
- Dir. of Survey
- Upstream
- Length Surveyed
- 320.8 ft.
- Total Length
- 320.8 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 2
Observation photos (2)
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
253.5 ft. - General Observation - 12" VCP
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 141.4 | TFC | Capped |
| 320.4 | DAGS | — |
| 253.5 | MGO | 12" VCP |
| 0 | MWL | — |
| 0 | AMH | 5:05AM |
| 320.4 | MGO | Conn. @ Mh, 3 O' Clock. Active |
| 320.8 | AMH | 5:25AM |
| 144 | TFC | Capped |
| 194.8 | TFC | Capped |
| 2 | DAGS | — |
| 197.3 | TFC | Capped |
| 0 | MWM | — |
Properties (3)
- additional_info
- GREASE INSPECTION ONLY
- customer
- LACSD
- datetime
- 2017-09-01T04:31:40-07:00
