Wastewater/Activity/PacpInspection/1.0Aug 17, 2017, 05:15 AM
02 1146_02 1145 _08162017_225623.mp4
- Date
- 08/16/2017
- W/O
- 646237
- Weather
- Dry
- Operator/Surveyor
- JUAN B
- Sewer ID
- Z00351
- PipeID
- P02930
- Time
- 10:15 PM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K4690
- Sewer Name
- 02 GARFIELD AVENUE EXTENSION TRUNK
- City
- MONTEBELLO
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 13
- Purpose
- Routine Assessment
- Project
- WO_646237_TV02244_JUL2017
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 12 in.
- Width
- 12 in.
- Upstream MH
- 02 1146
- Downstream MH
- 02 1145
- Dir. of Survey
- Downstream
- Length Surveyed
- 316.2 ft.
- Total Length
- 316.2 ft.
- Structural Index
- 3
- Structural Quick
- 3K2A
- Structural Rating
- 206
- O&M Index
- 2
- O&M Quick
- 2L00
- O&M Rating
- 126
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 332
Observation photos (2)
1.9 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
4.5 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 315.6 | MGO | CAPPED CONNECTION AT 9 OC |
| 94.2 | MWLS | — |
| 45.7 | MWLS | — |
| 0 | AMH | 02 1146 |
| 4.5 | CM | — |
| 316.1 | CM | — |
| 316.1 | DAGS | — |
| 0 | MWL | — |
| 1.9 | DAGS | — |
| 316.2 | AMH | 02 1145 |
| 0 | MWM | — |
| 316.1 | MGO | CAPPED CONNECTION AT 3 OC |
Properties (5)
- additional_info
- SC345629
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-08-16T22:15:23-07:00
- sewer_category
- Gravity
