Wastewater/Activity/PacpInspection/1.0Jun 1, 2017, 08:12 AM
H 0768A_H 0768 _20170601_022441.mp4
- Date
- 06/01/2017
- W/O
- 635495
- Weather
- Dry
- Operator/Surveyor
- JUAN B
- Sewer ID
- Z00942
- PipeID
- P11177
- Time
- 1:12 AM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K4535
- Sewer Name
- H JOINT OUTFALL H - UNIT 9C
- City
- COVINA
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 22
- Page No.
- 25
- Purpose
- Routine Assessment
- Project
- WO_635495_TV22079_MAY2017
- Material
- NRCP
- Shape
- Circular
- Height
- 22 in.
- Width
- 22 in.
- Upstream MH
- H 0768
- Downstream MH
- H 0768A
- Dir. of Survey
- Upstream
- Length Surveyed
- 78 ft.
- Total Length
- 78 ft.
- Structural Index
- 1
- Structural Quick
- 1B00
- Structural Rating
- 15
- O&M Index
- 3
- O&M Quick
- 513B
- O&M Rating
- 50
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 65
Observation photos (3)
1.2 ft. - Deposits Attached Grease, 20 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
1.2 ft. - Surface Roughness Increased, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
77.3 ft. - Deposits Attached Grease, 40 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 77.3 | SRI | — |
| 0 | MWL | — |
| 78 | DAGS | — |
| 78 | MSA | REVERSAL COMPLETED |
| 0 | MGO | — |
| 0 | AMH | H 0768 |
| 0 | MWM | — |
| 1.2 | DAGS | — |
| 77.3 | DAGS | — |
| 1.2 | SRI | — |
Properties (5)
- additional_info
- SC340750
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2017-06-01T01:12:18-07:00
- sewer_category
- Gravity
