Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Aug 29, 2017, 04:36 PM

  • 22 0279_22 0278_8292017_103609.mp4

Date
08/29/2017
W/O
0660015
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z00793
PipeID
P16565
Time
9:36 AM
Certificate
U-514-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7502
Sewer Name
22 CAMERON TRUNK, SECTS 1,2,&3
City
WEST COVINA
Loc. details
Sidewalk
Location Code
F
Use of Sewer
Sanitary Sewer
District
District 22
Page No.
31
Purpose
Routine Assessment
Project
20170829DF_CAMERON_TRUNK_SECTS_1_2_3
Material
NRCP
Shape
Circular
Height
15 in.
Upstream MH
22 0278
Downstream MH
22 0279
Dir. of Survey
Upstream
Length Surveyed
2 ft.
Total Length
2 ft.
Structural Index
3
Structural Quick
3121
Structural Rating
5
O&M Index
5
O&M Quick
5141
O&M Rating
9
Overall Index
4
Overall Quick
—
Overall Rating
14
Pipe schematic from manhole 22 0278 to 22 0279
MH: 22 0278MH: 22 0279upstream0 ft. LU - Alignment Up, 45 %0 ft. SAVC - Surface Aggregate Visible Chemical, from 08 to 04 o'clock, within 8 inches of joint: YES0 ft. MGP - General Photograph - HOLE0 ft. MGP - General Photograph0 ft. MSA - Survey Abandoned - 10:43 AM0 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES0 ft. MGP - General Photograph1.9 ft. MWL - Water Level, 100 %of cross sectional area1.9 ft. MWM - Water Mark, 100 %of cross sectional area2 ft. AMH - Downstream Manhole, Survey Begins - 10:34 AM2 ft. MGP - General Photograph - HOLE @ 12 O'CLOCK

Observation photos (6)

  • General Photograph - HOLE @ 12 O'CLOCK

    0 ft. - General Photograph - HOLE @ 12 O'CLOCK

  • Surface Aggregate Visible Chemical, from 08 to 04 o'clock, within 8 inches of joint: YES

    2 ft. - Surface Aggregate Visible Chemical, from 08 to 04 o'clock, within 8 inches of joint: YES

  • General Photograph - HOLE

    2 ft. - General Photograph - HOLE

  • General Photograph

    2 ft. - General Photograph

  • Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES

    2 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES

  • General Photograph

    2 ft. - General Photograph

All inspections of P16565Work order 0660015

Observations (11)

DistanceCodeObservation
2LU—
2SAVC—
0.1MWL—
0AMH10:34 AM
2MGPHOLE
2MGP—
0MGPHOLE @ 12 O'CLOCK
2MSA10:43 AM
2SSS—
0.1MWM—
2MGP—

Properties (4)

additional_info
VIEW FROM THE UPLEG OF THE D/S SIPHON (EAST BARREL)
custom_field_two
1
customer
LACSD
datetime
2017-08-29T09:36:16-07:00
