Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jul 27, 2017, 08:38 AM

  • 15 0579_15 0578 _072717_014146.mp4

Date
07/27/2017
W/O
646744
Weather
Dry
Operator/Surveyor
JUAN B
Sewer ID
Z00629
PipeID
P12508
Time
1:38 AM
Certificate
U-715-07000770
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K4669
Sewer Name
15 SANTA ANITA OUTFALL TRUNK
City
ARCADIA
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
04
Purpose
Routine Assessment
Project
WO_646744_TV15144_JUL2017
Material
Vitrified Clay Pipe
Shape
Circular
Height
21 in.
Width
21 in.
Upstream MH
15 0579
Downstream MH
15 0578
Dir. of Survey
Downstream
Length Surveyed
254.1 ft.
Total Length
254.1 ft.
Structural Index
3
Structural Quick
413E
Structural Rating
96
O&M Index
2
O&M Quick
2I12
O&M Rating
102
Overall Index
2
Overall Quick
—
Overall Rating
198
Pipe schematic from manhole 15 0579 to 15 0578
MH: 15 0579MH: 15 0578downstream0 ft. MGO - General Observation - CONNECTION AT 9 OC0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 15 05790 ft. MWM - Water Mark, 30 %of cross sectional area3.3 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start3.7 ft. VC - Vermin Cockroach77.7 ft. RPPD - Repair Patch Defective, from 09 to 03 o'clock, within 8 inches of joint: NO - VCP83.7 ft. TB - Tap Break-In, at 12 o'clock, -, within 8 inches of joint: NO, 4"89.7 ft. CL - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: YES102.1 ft. CL - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: NO105.9 ft. CL - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: YES, Start113.9 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Start113.9 ft. CL - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: YES, Finish141.6 ft. MGO - General Observation - CONCRETE PIPE 3 T0 9186.3 ft. RFJ - Roots Fine Joint, from 01 to 05 o'clock, within 8 inches of joint: YESR253.7 ft. MGO - General Observation - CONNECTION AT 3 OC254.1 ft. MGO - General Observation - CONNECTION AT 9 OC254.1 ft. AMH - Downstream Manhole, Survey Ends - 15 0578254.1 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish254.1 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish

Observation photos (7)

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    3.3 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Repair Patch Defective, from 09 to 03 o'clock, within 8 inches of joint: NO - VCP

    77.7 ft. - Repair Patch Defective, from 09 to 03 o'clock, within 8 inches of joint: NO - VCP

  • Crack Longitudinal, at 02 o'clock, within 8 inches of joint: YES

    89.7 ft. - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 02 o'clock, within 8 inches of joint: NO

    102.1 ft. - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: NO

  • Crack Longitudinal, at 02 o'clock, within 8 inches of joint: YES, Start

    105.9 ft. - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: YES, Start

  • Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

    113.9 ft. - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

  • General Observation - CONCRETE PIPE 3 T0 9

    141.6 ft. - General Observation - CONCRETE PIPE 3 T0 9

All inspections of P12508Work order 646744

Observations (20)

DistanceCodeObservation
186.3RFJ—
253.7MGOCONNECTION AT 3 OC
102.1CL—
77.7RPPDVCP
83.7TB—
0MGOCONNECTION AT 9 OC
254.1MGOCONNECTION AT 9 OC
113.9CM—
3.7VC—
105.9CL—
113.9CL—
0MWL—
3.3DAGS—
89.7CL—
0AMH15 0579
141.6MGOCONCRETE PIPE 3 T0 9
254.1AMH15 0578
0MWM—
254.1CM—
254.1DAGS—

Properties (5)

additional_info
SC345607
custom_field_two
3
customer
LACSD
datetime
2017-07-27T01:38:28-07:00
sewer_category
Gravity
