Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jul 19, 2017, 07:08 AM

  • 02 1544A_02 1544_19072017_000837.mp4

Date
07/19/2017
W/O
646606
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00230
PipeID
P03973
Time
12:08 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4653
Sewer Name
02 ARIZONA AVENUE TRUNK, SECTION 1
City
EAST LOS ANGELES
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
12
Purpose
Routine Assessment
Project
WO_646606_TV02006_JUL2017
Material
Vitrified Clay Pipe
Shape
Circular
Height
18 in.
Width
18 in.
Upstream MH
02 1544A
Downstream MH
02 1544
Dir. of Survey
Downstream
Length Surveyed
191.6 ft.
Total Length
191.6 ft.
Structural Index
3
Structural Quick
3F00
Structural Rating
111
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
111
Pipe schematic from manhole 02 1544A to 02 1544
MH: 02 1544AMH: 02 1544downstream0 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK0 ft. AMH - Upstream Manhole, Survey Begins - 02 1544A0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. MWM - Water Mark, 15 %of cross sectional area6.2 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start99.1 ft. TB - Tap Break-In, at 02 o'clock, -, within 8 inches of joint: NO, 6"112.3 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: NO, 6"150.4 ft. TB - Tap Break-In, at 02 o'clock, -, within 8 inches of joint: NO, 6"181.5 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: NO, 6"191.6 ft. AMH - Downstream Manhole, Survey Ends - 02 1544191.6 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish

Observation photos (4)

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    6.2 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Tap Break-In, at 02 o'clock, -, within 8 inches of joint: NO, 6"

    99.1 ft. - Tap Break-In, at 02 o'clock, -, within 8 inches of joint: NO, 6"

  • Tap Break-In, at 10 o'clock, -, within 8 inches of joint: NO, 6"

    112.3 ft. - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: NO, 6"

  • Tap Break-In, at 10 o'clock, -, within 8 inches of joint: NO, 6"

    181.5 ft. - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: NO, 6"

All inspections of P03973Work order 646606

Observations (11)

DistanceCodeObservation
0MGOCONNECTION AT MH 9 O'CLOCK
99.1TB—
150.4TB—
6.2CM—
191.6AMH02 1544
191.6CM—
0AMH02 1544A
0MWL—
0MWM—
181.5TB—
112.3TB—

Properties (5)

additional_info
SC345513
custom_field_two
3
customer
LACSD
datetime
2017-07-19T00:08:14-07:00
sewer_category
Gravity
