Wastewater/Activity/PacpInspection/1.0Aug 29, 2017, 04:31 PM
22 0279_22 0278_8292017_102710.mp4
- Date
- 08/29/2017
- W/O
- 0660015
- Weather
- Dry
- Operator/Surveyor
- FRANKLIN
- Sewer ID
- Z00793
- PipeID
- P20195
- Time
- 9:31 AM
- Certificate
- U-514-06024039
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- G7502
- Sewer Name
- 22 CAMERON TRUNK, SECTS 1,2,&3
- City
- WEST COVINA
- Loc. details
- Sidewalk
- Location Code
- F
- Use of Sewer
- Sanitary Sewer
- District
- District 22
- Page No.
- 31
- Purpose
- Routine Assessment
- Project
- 20170829DF_CAMERON_TRUNK_SECTS_1_2_3
- Material
- NRCP
- Shape
- Circular
- Height
- 8 in.
- Upstream MH
- 22 0278
- Downstream MH
- 22 0279
- Dir. of Survey
- Upstream
- Length Surveyed
- 2.4 ft.
- Total Length
- 2.4 ft.
- Structural Index
- 3
- Structural Quick
- 3121
- Structural Rating
- 5
- O&M Index
- 5
- O&M Quick
- 5141
- O&M Rating
- 9
- Overall Index
- 4
- Overall Quick
- —
- Overall Rating
- 14
Observation photos (2)
2.3 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES
2.3 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES
Observations (9)
| Distance | Code | Observation |
|---|---|---|
| 2.3 | SAV | — |
| 2.3 | MGO | CHIPPING 8 TO 4 O'CLOCK |
| 2 | LU | — |
| 2.4 | MSA | 10:32 AM |
| 2 | MWL | — |
| 2 | MGO | STOPLOG DOWN 5 T0 7 O'CLOCK |
| 0 | AMH | 10:00 AM |
| 2 | MWM | — |
| 2.3 | SSS | — |
Properties (4)
- additional_info
- VIEW FROM THE UPLEG OF THE D/S SIPHON (WEST BARREL)
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2017-08-29T09:31:57-07:00
