Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 26, 2017, 10:26 AM

  • 15 0130_15 0129 _26062017_034824.mp4

Date
06/26/2017
W/O
624421
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00634
PipeID
P12029
Time
3:26 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4593
Sewer Name
15 TYLER AVENUE TRUNK
City
EL MONTE
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
23
Purpose
Routine Assessment
Project
WO_624421_TV15037_JUN2017
Material
NRCP
Shape
Circular
Height
18 in.
Width
18 in.
Upstream MH
15 0129
Downstream MH
15 0130
Dir. of Survey
Upstream
Length Surveyed
378.9 ft.
Total Length
378.9 ft.
Structural Index
3
Structural Quick
3N00
Structural Rating
225
O&M Index
2
O&M Quick
4139
O&M Rating
181
Overall Index
3
Overall Quick
—
Overall Rating
406
Pipe schematic from manhole 15 0129 to 15 0130
MH: 15 0129MH: 15 0130upstream0 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 3 AND 9 O'CLOCK0 ft. AMH - Upstream Manhole, Survey Ends - 15 01302.4 ft. SAV - Surface Aggregate Visible, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish2.4 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish2.4 ft. RMJ - Roots Medium Joint, from 03 to 09 o'clock, 15 %, within 8 inches of joint: YESR, Finish48.3 ft. RMJ - Roots Medium Joint, from 03 to 09 o'clock, 15 %, within 8 inches of joint: YESR, Start82.4 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"101 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"131.7 ft. TFC - Tap Factory Made Capped, at 11 o'clock, -, within 8 inches of joint: NO, 6"221.7 ft. TFC - Tap Factory Made Capped, at 01 o'clock, -, within 8 inches of joint: NO, 6"227.9 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"258.9 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"292.8 ft. TFC - Tap Factory Made Capped, at 11 o'clock, -, within 8 inches of joint: NO, 6"330.1 ft. TFC - Tap Factory Made Capped, at 01 o'clock, -, within 8 inches of joint: NO, 6"351.4 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"376.9 ft. SAV - Surface Aggregate Visible, from 09 to 03 o'clock, within 8 inches of joint: YES, Start376.9 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start378.9 ft. MWL - Water Level, 20 %of cross sectional area378.9 ft. AMH - Downstream Manhole, Survey Begins - 15 0129378.9 ft. MWM - Water Mark, 50 %of cross sectional area378.9 ft. MGO - General Observation - 70% MAG COATING

Observation photos (3)

  • Surface Aggregate Visible, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

    2 ft. - Surface Aggregate Visible, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

  • Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

  • Roots Medium Joint, from 03 to 09 o'clock, 15 %, within 8 inches of joint: YESR, Start

    330.6 ft. - Roots Medium Joint, from 03 to 09 o'clock, 15 %, within 8 inches of joint: YESR, Start

All inspections of P12029Work order 624421

Observations (21)

DistanceCodeObservation
157.2TFC—
296.5TFC—
27.5TFC—
0MWL—
2SAV—
120TFC—
48.8TFC—
0AMH15 0129
378.9MGOACTIVE CONNECTION AT MH 3 AND 9 O'CLOCK
0MWM—
247.2TFC—
378.9AMH15 0130
86.1TFC—
2DAGS—
0MGO70% MAG COATING
151TFC—
277.9TFC—
330.6RMJ—
376.5SAV—
376.5DAGS—
376.5RMJ—

Properties (5)

additional_info
SC345420
custom_field_two
3
customer
LACSD
datetime
2017-06-26T03:26:38-07:00
sewer_category
Gravity
