Wastewater/Activity/PacpInspection/1.0Jun 2, 2016, 05:26 AM
Date
06/01/2016
W/O
574365
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z01125
PipeID
P13457
Time
10:26 PM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K3388
Sewer Name
B JOINT OUTFALL B - UNIT 6H
City
ALHAMBRA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
20
Purpose
Routine Assessment
Project
WO_574365_TV16044_JUNE2016
Material
BRICK
Shape
Circular
Height
27 in.
Width
27 in.
Upstream MH
B 1155
Downstream MH
B 1154
Dir. of Survey
Downstream
Length Surveyed
423.7 ft.
Total Length
423.7 ft.
Structural Index
2
Structural Quick
2100
Structural Rating
2
O&M Index
2
O&M Quick
2300
O&M Rating
6
Overall Index
2
Overall Quick
—
Overall Rating
8
Pipe schematic from manhole B 1155 to B 1154
MH: B 1155MH: B 1154downstream0 ft. MGO - General Observation - CONNECTION AT MH 9 OCLOCK0 ft. MWM - Water Mark, 25 %of cross sectional area0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - B 11558.4 ft. MMS - Mortar Missing Small, from 08 to 04 o'clock, Start96.2 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: NO, 6"196.6 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: NO, 6"296.5 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: NO, 6"305.4 ft. RFB - Roots Fine Barrell, from 10 to 03 o'clock, Start313.1 ft. RFB - Roots Fine Barrell, from 10 to 03 o'clock, Finish321 ft. RFB - Roots Fine Barrell, from 09 to 03 o'clock, Start344.5 ft. RFB - Roots Fine Barrell, from 09 to 03 o'clock, Finish368.2 ft. RFB - Roots Fine Barrell, from 09 to 03 o'clock, Start406.5 ft. RFB - Roots Fine Barrell, from 09 to 03 o'clock, Finish408.2 ft. MMS - Mortar Missing Small, from 08 to 04 o'clock, Finish421.7 ft. MGO - General Observation - CONNECTION AT MH 9 OCLOCK422.8 ft. MGO - General Observation - CONNECTION AT MH 3 OCLOCK423.7 ft. AMH - Downstream Manhole, Survey Ends - B 1154

Observation photos (4)

  • Mortar Missing Small, from 08 to 04 o'clock, Start

    8.4 ft. - Mortar Missing Small, from 08 to 04 o'clock, Start

  • Roots Fine Barrell, from 10 to 03 o'clock, Start

    305.4 ft. - Roots Fine Barrell, from 10 to 03 o'clock, Start

  • Roots Fine Barrell, from 09 to 03 o'clock, Start

    321 ft. - Roots Fine Barrell, from 09 to 03 o'clock, Start

  • Roots Fine Barrell, from 09 to 03 o'clock, Start

    368.2 ft. - Roots Fine Barrell, from 09 to 03 o'clock, Start

All inspections of P13457Work order 574365

Observations (18)

DistanceCodeObservation
296.5TF—
421.7MGOCONNECTION AT MH 9 OCLOCK
321RFB—
313.1RFB—
422.8MGOCONNECTION AT MH 3 OCLOCK
0MGOCONNECTION AT MH 9 OCLOCK
8.4MMS—
0MWM—
0MWL—
408.2MMS—
96.2TF—
423.7AMHB 1154
0AMHB 1155
196.6TF—
368.2RFB—
344.5RFB—
305.4RFB—
406.5RFB—

Properties (5)

additional_info
SC300388
custom_field_two
4
customer
LACSD
datetime
2016-06-01T22:26:27-07:00
sewer_category
Gravity
