Wastewater/Activity/PacpInspection/1.0Apr 21, 2017, 09:47 AM
21 0444_21 0443 _20170421_030144.mp4
- Date
- 04/21/2017
- W/O
- 630321
- Weather
- Dry
- Operator/Surveyor
- JUAN B
- Sewer ID
- Z00777
- PipeID
- P15652
- Time
- 2:47 AM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4511
- Sewer Name
- 21 MOUNT SAN ANTONIO TRUNK
- City
- WALNUT
- Loc. details
- Easement/Right of Way
- Location Code
- D
- Use of Sewer
- Sanitary Sewer
- District
- District 21
- Page No.
- 28
- Purpose
- Resurvey For Any Reason
- Project
- WO_630321_TV21046_APR2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 21 in.
- Width
- 21 in.
- Upstream MH
- 21 0444
- Downstream MH
- 21 0443
- Dir. of Survey
- Downstream
- Length Surveyed
- 86.4 ft.
- Total Length
- 86.4 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 2
- O&M Quick
- 2300
- O&M Rating
- 6
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 6
Observation photos (3)
5.1 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
18.7 ft. - Deposits Settled Compacted, 5 %of cross sectional area, from 03 to 06 o'clock, , within 8 inches of joint: YES
52 ft. - Deposits Attached Encrustation, 5 %of cross sectional area, from 08 to 04 o'clock, , within 8 inches of joint: YES
Observations (9)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWL | — |
| 0 | MWM | — |
| 86.4 | MGO | CONNECTION AT 9 OC |
| 86.4 | AMH | 21 0443 |
| 0 | AMH | 21 0444 |
| 5.1 | DAGS | — |
| 18.7 | DSC | — |
| 52 | DAE | — |
| 86.4 | DAGS | — |
Properties (4)
- additional_info
- SC340725
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2017-04-21T02:47:05-07:00
