Wastewater/Activity/PacpInspection/1.0Apr 20, 2017, 10:12 AM
18 0993_18 0992 _20042017_025625.mp4
- Date
- 04/20/2017
- W/O
- 630156
- Weather
- Dry
- Operator/Surveyor
- R.VARGAS
- Sewer ID
- Z00677
- PipeID
- P14847
- Time
- 3:12 AM
- Certificate
- U-209-211
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4270
- Sewer Name
- 18 LA HABRA HEIGHTS TRUNK, SECTION 1
- City
- WHITTIER
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 18
- Page No.
- 22
- Purpose
- Routine Assessment
- Project
- WO_630156_TV18008_APR2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 8 in.
- Width
- 8 in.
- Upstream MH
- 18 0993
- Downstream MH
- 18 0992
- Dir. of Survey
- Downstream
- Length Surveyed
- 81.6 ft.
- Total Length
- 81.6 ft.
- Structural Index
- 4
- Structural Quick
- 4100
- Structural Rating
- 4
- O&M Index
- 2
- O&M Quick
- 3122
- O&M Rating
- 8
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 12
Observation photos (3)
2.1 ft. - Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
11 ft. - Deposits Attached Grease, 10 %of cross sectional area, from 02 to 10 o'clock, , within 8 inches of joint: YES, Start
11.1 ft. - Water Level, Sag in pipe, 60 %of cross sectional area, Start
Observations (16)
| Distance | Code | Observation |
|---|---|---|
| 38 | MWLS | — |
| 2.1 | DAGS | — |
| 11.1 | MWLS | — |
| 11 | DAGS | — |
| 78.3 | MGO | MAGNESIUM COATING END |
| 81.6 | AMH | 18 0992 |
| 0 | AMH | 18 0993 |
| 15.1 | OBN | NOT VISIBLE |
| 0 | VC | — |
| 2.1 | MGO | MAGNESIUM COATING START |
| 0 | MWL | — |
| 37.9 | OBN | NOT VISIBLE |
| 11 | DAGS | — |
| 0 | MWM | — |
| 78.3 | DAGS | — |
| 0 | MGO | LINER |
Properties (6)
- additional_info
- SC306850
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2017-04-20T03:12:52-07:00
- lining
- CIPP
- year_laid
- 38344
