Wastewater/Activity/PacpInspection/1.0Apr 18, 2017, 05:52 AM
18 1033_18 1032 _04172017_225310.mp4
- Date
- 04/17/2017
- W/O
- 630156
- Weather
- Dry
- Operator/Surveyor
- R.VARGAS
- Sewer ID
- Z00677
- PipeID
- P14887
- Time
- 10:52 PM
- Certificate
- U-209-211
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4267
- Sewer Name
- 18 LA HABRA HEIGHTS TRUNK, SECTION 1
- City
- LA HABRA HEIGHTS
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 18
- Page No.
- 23
- Purpose
- Routine Assessment
- Project
- WO_630156_TV18008_APR2017
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 8 in.
- Width
- 8 in.
- Upstream MH
- 18 1032
- Downstream MH
- 18 1033
- Dir. of Survey
- Upstream
- Length Surveyed
- 275.2 ft.
- Total Length
- 275.2 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 2
- O&M Quick
- 2J11
- O&M Rating
- 109
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 109
Observation photos (2)
2.2 ft. - Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
142.2 ft. - General Photograph
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 275.2 | AMH | 18 1033 |
| 28.2 | VC | — |
| 0 | AMH | 18 1032 |
| 273.1 | DAGS | — |
| 2.2 | DAGS | — |
| 0 | MWM | — |
| 208.7 | TFA | — |
| 142.2 | MGP | — |
| 13.4 | MGO | LINER |
| 275.2 | MGO | CONNECTION AT MH 3 O'CLOCK ACTIVE |
| 0 | MGO | CONNECTION AT MH 3 O'CLOCK ACTIVE |
| 0 | MWL | — |
Properties (6)
- additional_info
- SC306847
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2017-04-17T22:52:45-07:00
- sewer_category
- Gravity
- year_laid
- 38344
