Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Apr 12, 2017, 07:59 AM

  • 01 1371_01 1370_12042017_010011.mp4

Date
04/12/2017
W/O
630043
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00197
PipeID
P21610
Time
12:59 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4425
Sewer Name
01 BULLIS ROAD-TEMPLE STREET TRUNK
City
LYNWOOD
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
17
Purpose
Routine Assessment
Project
WO_630043_TV01008_APR2017
Material
Vitrified Clay Pipe
Shape
Circular
Height
21 in.
Width
21 in.
Upstream MH
01 1371
Downstream MH
01 1370
Dir. of Survey
Downstream
Length Surveyed
384.8 ft.
Total Length
384.8 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
2N00
O&M Rating
152
Overall Index
2
Overall Quick
—
Overall Rating
152
Pipe schematic from manhole 01 1371 to 01 1370
MH: 01 1371MH: 01 1370downstream0 ft. MWM - Water Mark, 30 %of cross sectional area0 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 3 O'CLOCK0 ft. MWL - Water Level, 25 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 01 13712 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start384.2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish384.3 ft. MGO - General Observation - COCKROACHES IN MANHOLE384.8 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 3 O'CLOCK384.8 ft. AMH - Downstream Manhole, Survey Ends - 01 1370

Observation photos (2)

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • General Observation - COCKROACHES IN MANHOLE

    384.3 ft. - General Observation - COCKROACHES IN MANHOLE

All inspections of P21610Work order 630043

Observations (9)

DistanceCodeObservation
384.2DAGS—
0MWM—
0MGOACTIVE CONNECTION AT MH 3 O'CLOCK
384.3MGOCOCKROACHES IN MANHOLE
384.8MGOACTIVE CONNECTION AT MH 3 O'CLOCK
2DAGS—
0MWL—
384.8AMH01 1370
0AMH01 1371

Properties (6)

additional_info
SC306994
custom_field_two
4
customer
LACSD
datetime
2017-04-12T00:59:48-07:00
sewer_category
Gravity
year_laid
35417
