Wastewater/Activity/PacpInspection/1.0May 10, 2017, 05:53 AM
F 0253_F 0252 _09052017_222631.mp4
- Date
- 05/09/2017
- W/O
- 630341
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00036
- PipeID
- P10176
- Time
- 10:53 PM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4448
- Sewer Name
- F JOINT OUTFALL F - UNIT 3A RELIEF
- City
- CERRITOS
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 39
- Purpose
- Routine Assessment
- Project
- WO_530341_TV02230_APR2017
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 66 in.
- Width
- 66 in.
- Upstream MH
- F 0253
- Downstream MH
- F 0252
- Dir. of Survey
- Downstream
- Length Surveyed
- 540.3 ft.
- Total Length
- 540.3 ft.
- Structural Index
- 3
- Structural Quick
- 5U3U
- Structural Rating
- 1068
- O&M Index
- 2
- O&M Quick
- 2U00
- O&M Rating
- 216
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 1284
Observation photos (4)
2 ft. - Surface Reinforcement Visible, from 10 to 02 o'clock, within 8 inches of joint: YES, Start
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
2 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
31 ft. - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWL | — |
| 2 | SRV | — |
| 2 | DAGS | — |
| 540.3 | SSS | — |
| 0 | MWM | — |
| 0 | AMH | F 0253 |
| 540.3 | SAP | — |
| 540.3 | AMH | F 0252 |
| 540.3 | DAGS | — |
| 540.3 | SRV | — |
| 31 | SSS | — |
| 2 | SAP | — |
Properties (6)
- additional_info
- SC345223
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2017-05-09T22:53:38-07:00
- sewer_category
- Gravity
- year_laid
- 27333
