Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Mar 17, 2017, 08:04 AM

  • 29 0272A_29 0272 _17032017_010516.mpg

Date
03/17/2017
W/O
624460
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00550
PipeID
P24180
Time
1:04 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4383
Sewer Name
29 WEST HILL STREET SEWER
City
SIGNAL HILL
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 29
Page No.
03
Purpose
Routine Assessment
Project
WO_624460_TV29035_MAR2017
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
8 in.
Width
8 in.
Upstream MH
29 0272
Downstream MH
29 0272A
Dir. of Survey
Upstream
Length Surveyed
343.4 ft.
Total Length
343.4 ft.
Structural Index
2
Structural Quick
3122
Structural Rating
7
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
2
Overall Quick
—
Overall Rating
7
Pipe schematic from manhole 29 0272 to 29 0272A
MH: 29 0272MH: 29 0272Aupstream0 ft. AEP - End of Pipe - 29 0272A2 ft. TF - Tap Factory Made, at 03 o'clock, -, within 8 inches of joint: NO, 6"43 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"45.6 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"95.4 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"97.9 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"134 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"136.9 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"167.1 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"185 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"189.5 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"235.6 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"238.4 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"244.1 ft. TBA - Tap Break-In Active, at 03 o'clock, -, within 8 inches of joint: NO, 6"264.5 ft. CL - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES273.8 ft. TF - Tap Factory Made, at 09 o'clock, -, within 8 inches of joint: NO, 6"283.3 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"290.6 ft. CL - Crack Longitudinal, at 09 o'clock, within 8 inches of joint: YES313.4 ft. TF - Tap Factory Made, at 09 o'clock, -, within 8 inches of joint: NO, 6"318.1 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES331.5 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"343.4 ft. MWM - Water Mark, 5 %of cross sectional area343.4 ft. AMH - Downstream Manhole, Survey Begins - 29 0272343.4 ft. MWL - Water Level, 5 %of cross sectional area

Observation photos (4)

  • Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

    25.3 ft. - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 09 o'clock, within 8 inches of joint: YES

    52.8 ft. - Crack Longitudinal, at 09 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

    78.9 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

  • Tap Break-In Active, at 03 o'clock, -, within 8 inches of joint: NO, 6"

    99.3 ft. - Tap Break-In Active, at 03 o'clock, -, within 8 inches of joint: NO, 6"

All inspections of P24180Work order 624460

Observations (24)

DistanceCodeObservation
107.8TFC—
69.6TF—
60.1TFC—
78.9CL—
30TF—
158.4TF—
343.4AEP29 0272A
176.3TFC—
245.5TF—
52.8CL—
297.8TF—
209.4TF—
0MWM—
0AMH29 0272
99.3TBA—
11.9TFC—
300.4TF—
153.9TF—
341.4TF—
0MWL—
206.5TFC—
248TFC—
25.3CM—
105TFC—

Properties (4)

additional_info
SC306892
custom_field_two
4
customer
LACSD
datetime
2017-03-17T01:04:38-07:00
